Specifications
Specifications 1. Best Selling OBD ii Tools with High Speed2. Work on iPhone for Vehicle Diaganostic Tools
3. WIFI OBD2 / O
OBD ii Tools with High Speed Work on iPhone for Vehicle Diaganostic Tools
Description:
The chip is ARM chip which speed is more faster and the communication speed is doubled than before one(CLK DEVICE).
the shape looks elegant and refined, the design is near the Apple style,compared the (CLK DEVICE),this new device is more exquisite,it doesn’t using the cable but (CLK DEVICE)having.
Features:
- The chip is using ARM chip which is twice faster.
- Protocal communicating speed is also twice faster than WIFI (CLK DEVICE)
- Cute and portable design without the long cable.
- Automatically power off, power save function.
- It helps a lot for saving power.
- Support all WIFI system ( Android, PC,WINCE,IPHONE,IPAD ect. ),
- Allocate address freely, not traditional ADHOC address mode any more.
- Offers simple connecting way for customers.
- Best Selling OBD ii Tools with High Speed Work on iPhone for Vehicle Diaganostic Tools .
Usage:
- Plug the scantool into Car OBDII female socket which is usually below the driving wheel.
- Insert car key and switch to Accessory ON position for static data reading.
- Scan the iCar from your Desktop/Notebook PC/PDA wifi device.
- Find "BUYOBD" to link. Enter password which is on the item label.
- You may switch car key to Start position to read more dynamic data readings.
Specifications:
OBDII decode chip: |
ARM 16bit MCU |
Firmware: |
ELM327 Version 1.4b compatible |
Transfer baud rate: |
4800 / 9600 / 10400 / 38400 / 500K |
Input interface: |
OBDII male 16pin |
Output interface: |
Wifi 802.11 b/g |
LED Indicator: |
Power(red) / OBD(green) / Link(blue) (PC or smart phone) |
Operating Voltage: |
12V, including over voltage /shortage protection |
Nominal Idle current: |
45mA |
Net Weight: |
31g |
Gross Weight: |
60g |
Wire Length: |
0 cm |
Password: |
See item label |
IP: |
192.168.0.10 |
HTTP local port: |
35000 |
Encryption: |
WEP128 |
Power: |
Supplied by car OBD socket |
Support OBDII/EOBD2 Protocols:
ISO 15765-4 (CAN-B 125Kbps, started since 2003 in USA)
ISO 15765-4 (CAN-C 500Kbs, 11bit ID, 29bit ID, started since 2003 in USA)
ISO 14230-4 (KWP2000)
ISO 9141-2 (5 baud init. 10.4 kbaud, replaced by 14230-4 gradually, stopped in USA in 2008)
SAE J1850 VPW (10.4 kbaud, replaced by 14230-4 gradually, stopped in USA in 2008)
SAE J1850 PWM (41.6 kbaud, replaced by 14230-4 gradually, stopped in USA in 2008)
SAE J1939 the Data link connector standard
Buyer vehicles test feedback
Other vehicle test result of ELM327
Compatible Vehicles:
Benz 2001/02/03 W203 C200K (ISO)
BMW X5 2002 (ISO) -3, -5/X5/Z3/Z4/Z8/740I/740L/750IL, (ISO1941) Chevrolet Aveo (ISO)
Citroen C3 2004 (ISO)
Daihatsu YRV 2005 (ISO)
Daihatsu YRV Turbo 2006 (ISO)
Fiat Tipo 2002 (ISO)
Ford New ocus 2006(CAN)
Honda Accord 2006 JDM (ISO)
Honda Accord Euro R 2004 JDM (ISO)
Honda City GD8 (ISO)
Honda Civic ES 1.6A (ISO)
Honda Integra Type R DC5 JDM (ISO)
Honda Jazz 1.4M (ISO)
Hyundai Accent 2004 (ISO)
Hyundai Getz 1.3A 2004 (ISO)
Hyundai Getz 1.6M 2004 (ISO)
Hyundai Matrix 2004 (ISO)
Hyundai Santa Fe 2.4A (ISO)
Hyundai Sonata GLS (ISO)
Hyundai Sonata 2005 (ISO)
Hyundai Tuscani FX (ISO)
Kia Carens 2005 (ISO)
Kia Magentis 2005 (ISO)
Kia Rio LS (ISO)
Kia Sorento SUV 2005 (ISO)
Lexus es300 Mazda 2 (CAN)
Mazda 5 (CAN)
Mazda 6 (CAN)
Mazda Premacy 2001 (ISO)
Mazda RX8 (CAN)
Mitsubishi Colt 2003 (ISO)
Mitsubishi Colt Plus 2005 (ISO)
Mitsubishi Eclipse (GST--Turbo Car can be tested for the year 1995-2000; 8.2 * 4.6 * 2cm RS/GS 1994-1996 GS all can do; Turbo Car for the year 1996-2000, only have speed and TPS, can clear the DTCS)
Mitsubishi Lancer Evolution IX 2006 (ISO)
Mitsubishi Pajero 3.5 V6 2006 (ISO)
Nissan Sunny B14 (ISO)
Nissan Sunny VIP FB15 (ISO)
Nissan X-Trail 2.0L 2004 (ISO)
Nissan X-Trail 2.5L 2004 (ISO)
Peugeot 206 2001 Only can show RPM
Peugeot 206 (ISO)
Peugeot 307 (ISO)
Peugeot 407 (ISO)
Renault Megane II 2005 (ISO)
Renault Kangoo 2006 (ISO)
Subaru Impreza 1.6TS 2002 (ISO)
Subaru Impreza WRX 2005 (ISO)
Toyota Camry 2.0A 2004 (ISO)
Toyota Camry 2.4A 2005 (ISO)
Toyota Corolla Altis 1.6A 2005 (ISO)
Toyota Corolla GLXi G8 1999 (ISO)
Toyota Corolla G9 2002 (ISO)
Toyota Vios 2004 (ISO)
Nissan Sunny (N16)
Nissan Cefiro (Teana) 2005
Nissan sentra 1.8 2000/2005
Nissan Cefiro (Teana) 2005
Proton Perdana V6
Subaru Legacy GT 2005
Toyota camry 2002
Toyota Wish JDM (Missing Pin 5 in DLC)
Toyota IST JDM (Missing Pin 5 in DLC)
Toyota altis 1.8 2004
Peugeot 206 2000
Suzuki Jimny 1.3 2000
Android: (supports bluetooth)
AlOBD scanner
DashCommand 2.9.1 by Palmer Performance
Torque by Ian Hawkins, Android 1.5/1.6/2.0/2.1
VoyagerDash by GTOSoft
Package Contents:
1 x OBD WIFI Scanner
1 x CD-ROM Software
Product Pictures:
