Help CenterRubber Fuel Pressure Hose for Automotive
Related Products
-
Rubber Braided Oil HoseUS$ 0.5 - 2.5MOQ: 1000 Meters -
Extruded 1.5 Inch Rubber HoseUS$ 0.1 - 2.5MOQ: 1000 Meters
-
Rubber Flexible Oil Hose Reel for AutomotiveUS$ 0.1 - 2.5MOQ: 1000 Meters
-
Rubber Flexible Oil Hose for AutomotiveUS$ 0.1 - 2.5MOQ: 1000 Meters
-
Rubber Fuel Hose Reel for AutomotiveUS$ 0.1 - 2.5MOQ: 1000 Meters
Specifications
1.TS 169491 factory2.Be used for automotive, motorcycle and universal machine
3.fuel pressure hose
Specifications: SAE J20BG710
SAE J20BC710
SAE J20CH710
SAE J20EE710
Construction: CR
NBR; NBR/CSM
ECO; ECO/CSM
ACM
ROHS,REACH compliant
Shape: straight or curve shape
Dimensions Range: 2.5 to 50mm
Temperature Range: -40 to 150 centigate
Performance: aging resistance, ozone resistance,oil resistance,chemical coolants resistance.
Application: for automotive, motorcycle, general machine
Raw Material :mostly import from foreign to ensure the material quality.
Rubber Mixing System:daily rubber mixing capacity is 8 tons, ensure the production needs.
Rubber Compression & Injection
name |
type |
Work plane |
200T quick hot press molding machine |
injection |
500*500mm |
300T quick hot press molding machine |
injection |
600*620 mm |
500T quick hot press molding machine |
injection |
750*750 mm |
250T quick hot press molding machine |
compression |
600*640 mm |
500T quick hot press molding machine |
compression |
750*750 mm |
500T quick hot press molding machine |
compression |
850*1600 mm |
Rubber Hose Extrusion
Deflashing
Full inspection and packing
QC control: Quality guarantee.
1. Tensile strength tester 2. Mooney Rheometer tester 3. Oil resistance tester 4. low-tempersture tester
5. Aging resistance tester 6. Ozone resistance tester 7. Porjector 8. Expanded tester
9. Bursting tester 10. Leakage tester 11. Hardness tester 12. The density test
Logistics
For samples or small quantity by air; For large quantity by sea
15 mins drive distance to Gaoqi airport.
20 mins drive distance to Xiamen port.
1.How long is sample lead time?
For prototype mold in 1 week; production mold in 2weeks; special mold in 3 weeks.
2.What document can you provide for new products?
For simple product ISIR and property test report available.
For vehicle part PPAP available
For special part according to customers` requests
3.What Payment terms can be accepted?
T/T,L/C at sight
