Negotiable MOQ: 500 Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
LED Light Source:
5050 SMD
Type:
Flex LED Strips
Input Voltage(V):
5V
Contact Supplier Request Quote Chat Now
Shenzhen Bangdao Electronic Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source 5050 SMD
Type Flex LED Strips
Input Voltage(V) 5V
Lamp Power 90W
Lamp Luminous Flux(lm) 850
Color Temperature(CCT) 3500K
Working Temperature(℃) -20, 50
Working Lifetime(Hour) 50000
Lamp Body Material ABS
Emitting Color RGB
Place of Origin Guangdong, China
Brand Name WS2812
Model Number WS2812

Tube Waterproof DC5V Dream Color Changing & Full Color Changing RGB WS2812 Flexible LED Strip Euipped with 5050 SMD







Pay attention:

White :  White PCB

Black :  Black PCB

IP30: Non- waterproof

IP65: Waterproof in Silicon Coating

IP67: Waterproof in Silicon Tube

30 leds: 30pcs 5050 smd per meter.150 leds/5 meters

60 leds: 60 pcs 5050 smd per meter,300 leds/5 meters



Input voltage:.............DC5v;

Power:.......................30leds/m----9watt/meter

            .......................60leds/m----18watt/meter

            .......................144leds/m----43.2watt/meter

LED resource:.............WS2812B led(5050 SMD RGB LED with built-in improved version of ws2811 ic)

LED: ...............each LED is separately controlled

IC Type: .....................improved version ws2812 IC(built inside the 5050 smd rgb led)

of IC: ..................(1 IC drives 1 led chip);

Pixels:.........                 30/60/144/meter;

Pitch: .........................16.6mm(1000/64);

Grey scale: ................256;

Bits/color: ...................8-bits/color;

FPC size: ....................Width: 10mm, High: 2.5mm;

FPC color: .........    BLACK/White

Protection rate...... IP30/ IP65 /IP67

Colors: ........................Full color RGB, dream color changing;

Cuttable:......................every LED is cuttable;

Package: ....................in anti-static bag,with 3M adhesive tape on the back



Packing List:

5 meters led strips ONLY





Product Description

Item Features:

    This LED strip is wrapped by a silica gel hose which provide excellent water and dust proof
    Low power consumption, Super-bright but running with low temperature
    All the light spread and completely smooth, luminous very even
    LED Type: ws2812

    Long lifespan >50,000 hours ,
    Available in different fixed colors and RGB (133changing modes can be realized)
    Controller is designed for the magic led strip which can be available133 modes

Specifications:

    LED Type: 5050 + WS2812 IC
    Power Consumption: 30

    30leds/m-7.2W/m,48leds/m-11.52W/m,60leds/m-14.4W/m


    Working Voltage: 5V
    Protection grade: IP67, Tube Waterproof
    Color: RGB
    Viewing angle: 120°
    storage temperature: -20°to 50°
    Size ( L X W X H ): 5000 x 10 x 2.5 mm



Easy installation
Dream color lighting

Match use controller can appear colorful curtain-up/ flow water/raindrop/jump flash and so on hundreds of lighting effect.



Application



Making led screen, led wall, advertising board. Apply to hotel, KTV, bars, advertisement company, decoration company, the city lighting project, entertainment and leisure places lighting.
