Specifications
Professional all in one garden solar light, CE&ISO Approved,Whole Night Lighting design, for Walkway, City Lighting, etc.All in One High Effecient 4M 15W Solar Garden Light
LED Solar Street Lighting System: LED Street Lighting is fresh new alternative to traditional street lamps such as: LPS, HPS or MH street lights.
LED Lighting provides a multitude of advantages over conventional incandescent lights.
Advantages of LED Solar Street Lighting Projects:
1). Green Energy, Lower Power Consumption, Save 60%-80% Than Others.
2). Higher power, higher brightness intensity, Good Color Rendition.
3). Save electricity cost. Save electric transformer and cable cost. Free maintenance
4). Environmental Impact - Eliminate Hazardous Disposal, Low Light Pollution, No Radiation.
5). Longer lifetime: Between 80000-100000 Hrs. If lighting 12 hrs/night, could use at least 12 - 22 Years
6). Less heat Generated compared to other sources,
7). Downward orientation of Light, could adjust lighting angles and lighting range and shape on the Ground to meet the road-Rectangular. Other lighting source just could give common round shape and small lighting range.
Technical Reference of 4M-15W Double LED Solar Garden Lighting System
Part Name & Lifespan
| Technical Specification |
Solar Panel Lifespan: 20~25 years | 60W*1PC Polycrystalline. High Efficiency. A-class Adding Aluminum Frame, Tempered Glass. |
Gelled Battery Lifespan: 5~8 years | 60Ah/12V*1PC, to get 24V, Gelled battery, Sealed Type. Deep cycle. Maintenance Free |
Intelligent Solar Controller Lifespan:5-10 years
| 10A/12V, IP68. Automatic Light and Time Control Over-charging/discharging Protection Reverse-connection Protection Switch on Automatically with Light Sensor; Switch off after designed Hours later |
Light source: High Power LED Lifespan: More than 50000-100000Hrs
| 15W LED, White Color, 1800LM,5600K, IP65 High Power, High Brightness. |
Lamp Housing: Lifespan: More than 20 years
| Die-casted Aluminum, IP65 High transmittance & Density toughened glass, |
Pole: Lifespan: More than 20 years
| 4M Height, Steel, Hot-Dip Galvanized. With Arm, Bracket, Flange, Fittings, Cable, Etc Resistant to Wind: ≥150KM/H, |
Battery Box:
| Engineering Plastic,Burying Type Battery |
A. LED and Lamp Fixture
1. Top quality chips and LEDs are used, achieving ultra brightness, saving energy by 75%;
2. Power factor over 95%, harmonic distortion rate less than 15%;
3. long lifetime over 80,000 hours.
4. Adopt digital constant-power technology, realizing control of LED power;
5. Unique die-casted aluminum shell structure realizing excellent cooling effect;
6. Lens light distribution technology is adopted, making the brightness more even;
7. Stable LED working point, low temperature rise, low brightness decline.
B. Battery
1. Real green power
2. Low internal resistance
3. Low self-discharging rate: less than 3% every month; lead-acid type less than 15%
4. Low gassing rate: only 5% of ordinary sealed battery
5. Long life design: greater than 1000 times at 25°C, ordinary battery is just 600 times; usually 5~8 years
6. Wider temperature range: -30°C~+55°C
7. Extremely good discharge recovery ability
C. Panle
Mono/Poly-crystal silicon high-efficiency cell with service life ≥25 years
Place of Origin: Yangzhou China (Mainland)
Brand Name: BR-Solar
Specification: Normal
Output Voltage (V): 12VDC 24V DC
Load Power (W): Depends
Solar Power (W): 5W--300W
System voltage: 12v or 24v
Glass: Low iron tempered glass
Frame: aluminum
Cable: MC-4 and connector
Size: Customized dimensions
D. Lamp Pole
Material :Q235
Height :3-5M
Finish :hot dip galvanized and powder coat
Including :bracket for solar panel and arm
Plate square:depends on the height of lamp post
Plate thickness:depends on the height of lamp post
E. Controller
Intelligent sensor
l Light / time/ power control
l Over charging/ discharging protection
l Short Circuit protection
Reverse polarity protection
Showcase
| |
| |
Our Certificates
| |
| |
So far, our products has been widely used in more than 52 countries, with CE, IEC, RoHS, SONCAP, CCC, FCC approved.
Owing to the high quality and professional service, we always recieve good feedback from our customers.
Please feel free to contact us if you have interest.
Application for your reference
