RECHARGEABLE VRLA AUTO BATTERY DEEP CYCLE BATTERY Lead Acid Battery

RECHARGEABLE VRLA AUTO BATTERY DEEP CYCLE BATTERY Lead Acid Battery thumbnail-1
RECHARGEABLE VRLA AUTO BATTERY DEEP CYCLE BATTERY Lead Acid Battery thumbnail-2
RECHARGEABLE VRLA AUTO BATTERY DEEP CYCLE BATTERY Lead Acid Battery thumbnail-3
RECHARGEABLE VRLA AUTO BATTERY DEEP CYCLE BATTERY Lead Acid Battery photo-1
RECHARGEABLE VRLA AUTO BATTERY DEEP CYCLE BATTERY Lead Acid Battery photo-2
RECHARGEABLE VRLA AUTO BATTERY DEEP CYCLE BATTERY Lead Acid Battery photo-3
US$ 180 - 220 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
BR
Model Number:
BR-Y1442
Contact Supplier Request Quote Chat Now
Yangzhou Bright Solar Solutions Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name BR
Model Number BR-Y1442
Type Other, Lead-acid, Lead-acid/Gel
Nominal Voltage 12V
Size Other, 523*240*225mm
Nominal Capacity 200Ah

Specifications

solar lead-acid battery:
1. deep cycle & long life
2. batteries for solar free maintaince
3. factory directly
4. OEM service

Deep cycle good quality AGM VRLA from 24ah to 250ah 12 volt solar battery







Product Description







12V lead acid battery Discharging Curve



RECHARGEABLE VRLA AUTO BATTERY DEEP CYCLE BATTERY lead acid battery



12V lead acid battery Charging Curve



RECHARGEABLE VRLA AUTO BATTERY DEEP CYCLE BATTERY lead acid battery



12V Battery Lead-Acid and Gelled is Available for Choosing

Model

Voltage

(V)

Capacity

   (AH)

Length

(mm)

Width

(mm)

Height

(mm)

Weight

(kg)

6-CAJ-24

12

24

165

125

175

7.1

6-CAJ-38

12

38

196

165

175

12.5

6-CAJ-50

12

50

327

170

175

17

6-CAJ-55

12

55

327

170

175

18.5

6-CAJ-65

12

65

327

170

175

20

6-CAJ-70

12

70

329

172

215

23

6-CAJ-75

12

75

329

172

215

24

6-CAJ-80

12

80

329

172

215

25

6-CAJ-90

12

90

329

172

215

27.5

6-CAJ-100

12

100

406

172

210

30

6-CAJ-120

12

120

406

172

210

32.5

6-CAJ-150

12

150

482

172

242

42.0

6-CAJ-200

12

200

523

240

225

57





2V Battery Lead-Acid and Gelled is Available for Choosing



Model

Voltage

(V)

Capacity

   (AH)

Length

(mm)

Width

(mm)

Height

(mm)

Weight

(kg)

CNF-200

2

200

172

111

330

13.5

CNF-300

2

300

171

151

330

19

CNF-400

2

400

211

176

330

25

CNF-500

2

500

241

171

330

29

CNF-600

2

600

301

175

330

35

CNF-800

2

800

410

175

330

48.5

CNF-1000

2

1000

475

175

330

61

CNF-1500

2

1500

401

351

342

95

CNF-2000

2

2000

491

351

344

125

CNF-3000

2

3000

710

350

368

180





  12V Solar Battery Lead-Acid and Gelled 2PC 12V in series to compose 24V

Nominal Voltage …………………............................................................................…… 12V

Number of cell ………………............................................................................………... 6

Design Life ………………………............................................................................……. 5-8 years

10 hour rate(12.0A,10.5V) ………..........................................................................…….200Ah

Fully Charged battery 77°F(25°C) ….........................................................................….4mΩ

Discharge …………………..………..........................................................................…. -20~60°C

Charge ……………………..………..........................................................................….. -10~60°C

Storage …………………………...........................................................................……… -20~60°C

Size: …………………………....................................................................................…… 523*240*225mm

Net Weight……………………............................................................................………...57.0KGS





Relation Between Effective Capacity and the Temperature
(Battery could work regularly between -30℃ to 55℃ )

RECHARGEABLE VRLA AUTO BATTERY DEEP CYCLE BATTERY lead acid battery



RECHARGEABLE VRLA AUTO BATTERY DEEP CYCLE BATTERY lead acid batteryRECHARGEABLE VRLA AUTO BATTERY DEEP CYCLE BATTERY lead acid battery







Company Information

About Our Company Certificatio

RECHARGEABLE VRLA AUTO BATTERY DEEP CYCLE BATTERY lead acid battery



RECHARGEABLE VRLA AUTO BATTERY DEEP CYCLE BATTERY lead acid battery



FAQ



FAQ:

1.Q:How many cycles full charge&discharge about your battery?

 A: In 50% discharging deepness, it can be cycled for 1,200 times; in floating charging and discharging status, it can be cycled for 5000~6000 times.


2.Q:How to Choose the System Voltage  12V or 24V or for normal street Light ?

A: We can design the System for 12v or 24v for solar street Light .


3.Q:What’s the wider temperature range

A:pr-30° to 55°,adapt well in different temperature and charge and discharge conditions.
