13 ohm TCR 1400 Ceramic Resistance Auto Heater for Car Sensor

1

Part No.

GR385

2

Usage

Ceramic Resistance Auto heater

3

Working Voltage

12VDC

4

Heating Resistance

13Ω(23°C±2°C)

5.

Current

Impulse current:no more than 1.0A; Stable current: no more than 0.56A

6

Heating speed

In 20 seconds the temperature to (410°C±60°C);

60 Seconds the temperature to (540°C±60°C)

7

Compression test

1500VAC,1 second;

Current leakage no more than 5ma(23°C±2°C)

8

Dimension of product

length:56mm, diameter3.0mm

9

Electrode

Welding nickel sheets on the surface of electrode

7

Advantages

(1)Long lifetime: airproof structure ; the condition of deformation .can’t exit

(2)Temperature rise quickly

(3)Excellent insulation

(4)Energy efficient and thermalconductivitysuper—heating simultaneously both from inside and outside

(5)Small and compact

(6)Equalized heat distribution and high power density.

(7)Meet RoHS requirement

(8)High cost performance.
