Temperature and humidity control telecom cabinet/Aluminum outdoor enclosure SK-320/Weatherproof & Customized design
| Specification for SK-320 Outdoor Cabinet | ||
| Cabinet | External dimenison | W650*D800*H1800mm (if include the heat exchanger, the cabinet depth is 910mm.) |
| Internal capacity | Battery rack ( 4 layers of the battery holder, the upper layer 200mm height space for equipments) | |
| Cooling system | 80w/k heat exchanger, use 48V DC power supply. The heat exchanger is installed in the door. | |
| Panel structure | Sanwitch panel structure
| |
| Panel Material | 1.5 mm -3.5mm thickness galvanized iron. (Optional: aluminum, stainless steel, cold-rolled steel) | |
| Color | RAL7035 grey or as as requirement | |
| Protection Level | IP54/IP55/IP65/IP66 | |
| Standard | IEC297-2; DIN41491;part1 | |
| Environment | Operating temperature | -10°C ~ + 45 °C |
| Storage temperature | -40°C ~+ 45 °C | |
| operating humilidity | -40°C ~ +45 °C | |
| Transporation temperature | 5% ~95% | |
| Others (optional) | lighting | 48V LED light (based on request) |
| sensors | Door, smoke, temeperature,water, humility (based on request) | |
| Cabinet bottom cable | There are some intake wire holes in the bottom.
| |
| Environment monitor | controller with integrated power. Signal input and alarm output. (Based on request) | |
| Package | Wood case. If the cabinet with air conditioner. The case must be vertically standing loaded | |
Heat Exchanger Type Outdoor Cabinet SK-320 (Other options: Air conditioning/Fan)
Factory general look:
Certificates and other patent
Other products
- Sample: Sample making is available before mass-manufacture.
- Delivery: 20-30 days after receipt the deposit.
- Factory Visit& Inspection: Welcome customer or your agent to visit our factory before order and loading.
Tianjin Yanxiang Electronic Science and Technology Co., Ltd., registered in Tianjin Binhai Hi-Tech industrial Zone.
It is a high-tech company with technology R&D and service combination as well as information and industry.
Meanwhile it is a High State Authenticated and New Technology Enterprise , Excellent Private Enterprise of Tianjin.
The company passed the ISO9001 International Quality System Certification in 2004 January.
We have acquired multiple software copyrights and invention patents.
Several product technologies are listed as National Key and New Product Project , Tianjin Science and Technology Support Plan Project.
1.Are you a manufacturer?
Yes.We have 13 years manufactural experience.
2.Can you ensure quality?
Yes.In the production of each link and before loading do a detailed inspection.
3.Can you keep timely delivery?
Yes.We use short producing time and fast shipping.
