25U Outdoor Electrical Cabinet

Name: 25U Outdoor Electrical Cabinet
Brand: Shiyu
SKU: 100858703
Availability: InStock

US$ 800 - 1,200 MOQ: 2 Sets

Key Specifications

Place of Origin:

Tianjin, China

Brand Name:

Shiyu

Model Number:

SK-305

Tianjin Yanxiang Electronic Science And Technology Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Tianjin, China

Brand Name Shiyu

Model Number SK-305

Protection Level IP55

Type Other, 25U outdoor electrical cabinet

External Size 650*870*1500mm (W*D*H)

Waterproof metal cabinet / 25U outdoor electrical cabinet

Air conditioner cooling outdoor enclosure 25U outdoor cabinet outdoor electronic cabinet

Technology Parameter

Model	SK-305
Size	6507201490mm(WDH) (The total depth is 870mm when including air conditioner).
Internal	19 inch standard Cabinet Racks ,25U
Cooling system	You can choose from : A.300W compress air conditioner B.80W/K heat exchanger C.200W TEC air conditioner D.Fans
Material	Galvanized steel(or aluminum/stainless steel)
Color	Grey (RAL7035) or according to customer requirements
Cabinet Standard	IEC297-2; DIN41491: PART1
Protection level	IP55 /(IP54 for fans type)
Lock	Turning Waterproof Lock
Structure	Sandwitch Structure:double layer with phenolic aldehyde insulation board filled between layers.
Cable hole	In the cabinet bottom, size and quantity according to customer requirement
Power Supply	220VAC±15%,50/60Hz for 300W compresser air conditioner 48VDC for heat exchanger and TEC air conditioner
Finish	Outdoor epoxy powder
Weight:	Galvanized steel netweight is 150kg / Aluminum cabinet netweight is 80kg
Package	Wooden case with pallet / Carton
Options	a.PDU b.Alarms c. LED light

Environmental Parameter

Operating temperature range: -15 ° C to +45 ° C

Storage temperature range: -25 ° C to +55 ° C

Transport temperature range: -40 ° C ~ +70 ° C

Relative humidity: 5% ~ 95% (+40 °C ± 2 °C)

Ambient pressure: 70kPa ~ 106kPa

Schematic diagram of the battery cabinet size:

Other outdoor enclosure from our company:

Other products

Product picture
Model Number	SK-305	SK-27B	SK-65125
External Size	6508701490mm (WDH)	6509101300mm (W DH)	6506501250mm (W DH)
Internal Capacity	25U,19 inch rack	22U ,19 inch rack	20U ,19 inch rack
Cooling System	Air conditioner (340W)	Heat exchanger(80W/K)	Heat exchanger(80W/K)
Color	RAL9002	RAL7035	RAL7035
Weight	150kg	123kg	90kg
Mount method	On the ground	On the ground	On the ground
Product picture
Model Number	SK-76105	SK-235	SK-320B
External Size	7605501050mm (W DH)	6007501000mm (WDH)	6507201650mm (W DH)
Internal Capacity	18U ,19 inch rack	18U,19 inch rack	28U ,19 inch rack
Cooling System	Heat exchanger(80W/K)	TEC Air conditioner (200W)	Heat exchanger(80W/K)
Color	RAL7035	RAL7035	RAL7035
Weight	74kg	80kg	150kg
Mount method	On the ground	Pole mounted	On the ground
Product picture
Model Number	SK-419	SK-65100	SK-1850
External Size	120011901800mm (W DH)	6507201000mm(W DH)	650650620mm(W DH)
Internal Capacity	Battery rack	Battery rack	10U ,19 inch rack
Cooling System	Heat exchanger(80W/K)	Heat exchanger(80W/K)	TEC air conditioner(120W)
Color	RAL7035	RAL7035	RAL7035
Weight	330kg	70kg	65kg
Mount method	On the ground	On the ground	Pole mounted
Place of Origin	Tianjin, China (Mainland)
Type	outdoor cabinet/outdoor telecom cabinet
Structural Materials	SPCC (cold rolled steel),aluminum,stainless steel, according to your demand
Structure characteristics	Double-layer heat insulation structure
Protection grade	IP55
package	Wooden case with pallet
