IP55 Outdoor/SK-35B telecom battery cabinet with heat exchanger
| Specification for SK-35B Outdoor Cabinet | ||
| Cabinet | External dimenison | W1070*D590*H1800mm |
| Internal capacity | Battery rack | |
| Cooling system | Fan (Optional: Air conditioner, heat exchanger, ventilation window) | |
| Panel structure | Sanwitch panel structure |
|
| Panel Material | 1.5 mm thickness galvanized iron (Optional: Aluminum, stainless steel, cold-rolled steel) | |
| Color | RAL7035 grey or as as requirement | |
| Protection Level | IP54/IP55/IP65/IP66 | |
| Standard | IEC297-2; DIN41491;part1 | |
| Environment | Operating temperature | -10°C ~ + 45 °C |
| Storage temperature | -40°C ~+ 45 °C | |
| operating humilidity | -40°C ~ +45 °C | |
| Transporation temperature | 5% ~95% | |
|
Others (optional) |
lighting | 48V LED light (based on request) |
| sensors | Door, smoke, temeperature,water, humility (based on request) | |
| cabinet bottom cable clamp and pole bracket size |
Cable: 2PG25, 2PG11 Bracket: 600*544mm
|
|
| Environment monitor | controller with integrated power. Signal input and alarm output. (Based on request) | |
| Package | Wood case. If the cabinet with air conditioner. The case must be vertically standing loaded | |
Outdoor cabinet SK-35B for your reference
Factory general view
Certificates and patent
Other products
- Sample: Sample making is available before mass-manufacture.
- Delivery: 20-30 days after receipt the deposit.
- Factory Visit& Inspection: Welcome customer or your agent to visit our factory before order and loading.
Tianjin Yanxiang Electronic Science and Technology Co., Ltd., registered in Tianjin Binhai Hi-Tech industrial Zone.
It is a high-tech company with technology R&D and service combination as well as information and industry.
Meanwhile it is a High State Authenticated and New Technology Enterprise , Excellent Private Enterprise of Tianjin.
The company passed the ISO9001 International Quality System Certification in 2004 January.
We have acquired multiple software copyrights and invention patents.
Several product technologies are listed as National Key and New Product Project , Tianjin Science and Technology Support Plan Project.
1.Are you a manufacturer?
Yes.We have 13 years manufactural experience.
2.Can you ensure quality?
Yes.In the production of each link and before loading do a detailed inspection.
3.Can you keep timely delivery?
Yes.We use short producing time and fast shipping.
