Help CenterIP55 Heat Exchanger YXH-02-SH
Related Products
-
Air to Air Heat Exchanger/YXH-02-DH/heat ExchangerUS$ 400 - 600MOQ: 1 Set -
AIR HEAT EXCHAGER FOR OUTDOOR COMMUNICATION CABINETUS$ 300 - 1,000MOQ: 1 Set
-
Air Heat Exchanger Cabinet Heat Exchanger 80W/K Heat ExchangerUS$ 300 - 400MOQ: 10 Sets
-
Heat Exchanger for Telecom Cabinet (YXH-) /self-own Design BrandUS$ 400 - 700MOQ: 10 Sets
-
80W/K for Industrial Heat Exchanger of Outdoor Cabinet Counterflow Air Heat ExchangerUS$ 400 - 500MOQ: 1 Piece
Specifications
Industrial heat exchanger/heat exchangerYXH-02-DH1Model Number: YXH-02-SH
2Structure: Tube Heat Exchanger
heat exchanger/heat exchanger with protection classIP55 YXH-02-SH
Series
YXH-02-DH |
YXH-02-SH |
YXH-03-SH |
YXH-04-DH |
YXH-05-DH |
|
Dimensions(mm) |
925x355x156 |
924x354x153 |
1268x416x195 |
1274x514x195 |
1403x684x246 |
Working environment |
Temperature:-40 ~ +65 °C (-40 ~ +155 °F) Humidity:0 ~ 100% |
||||
Safety performance |
Water and dust proof, protection level IP 55, nonmetallic material inflaming retarding, anti-shock and vibration |
||||
|
Environmental performance |
Noise sound pressure level≤60 dB (45°C); Meeting the green environment protection requiremnet by RoHS and WEEE; Conforming to EU envionmental protection instruction such as 94_62_EEC,2002_95_EEC,2002_96_EEC |
||||
Reliability |
In the case of working continually under 40°C, the fans’ life span is longer than 40,000 hours |
||||
Temperature Regulation |
internal circulation temperature>35 °C, external circulation fans on internal circulation temperature< 30 °C, external circulation fans off internal circulation temperature< 5 °C, internal heater on internal circulation temperature>15 °C, internal heater off |
||||
System monitor |
5 way switch alarm |
2 way switch alarm |
2 way switch alarm |
5 way switch alarm |
5 way switch alarm |
Panel indicator | |||||
High and low temperature alarm setup and checking | |||||
Serial Port checking | |||||
Serial Port control fans’ rotating speed | |||||
Coefficient of heat transfer |
80w/k |
80w/k |
120w/k |
190w.k |
220w/k |
Heater |
800W |
1000W |
800W |
1600W |
1600W |
Overheat protection, automatic or manual reset protection | |||||
No-load current |
25 mA MAX (INPUT 230VAC 50Hz) |
||||
DC INPUT |
19– 30 VDC |
38 – 58 VDC |
38 – 58 VDC |
38 – 58 VDC |
38 – 58 VDC |
AC INPUT |
220 VAC ± 20% 50Hz |
||||
