Product Details
Condition: | New | Type: | Cabinet Air Conditioner | Place of Origin: | Tianjin, China |
Brand Name: | SHIYU | Model Number: | 300W TEC Peltier | Operating Voltage: | Other, 48v dc/24v dc |
Mounting: | Wall / Window Mount | Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
Wooden case/Carton case with pallets
Product Description
2015 Best seller cabinet form a complete set of air conditioning 300W 48V DC cooling unit/function
Product introduction:
What is Peltier TEC Air-conditioner:
TEC air conditioner is automatic temperature control equipment using peltier refrigeration.
The Peltier TEC Air-conditioner advantages:
The internal intelligent control system, automatic control peltier device to produce cool and heat dissipation fans operate.
There is LED display screen and key-press board, friendly operation interface.
The control system offering RS485 connector, can connect with the remote computer, achieve the remote monitoring function.
Range of use:
This product widely used in medium and small machine room, UPS room, operators outdoor base station equipment room, bank ATM teller machine change money room etc.
Technical parameter of Peltier TEC air-conditioner cooler (100w-400w capacity):
Model | 100WTEC | 200WTEC | 300W efficient TEC | 400W efficient TEC | |
Working voltage (V) | DC48V | DC48V | DC48V | DC48V | |
The performance parameters | |||||
Rated input current-A | L25 | 3.5 | 7.0 | 8 | 10 |
L35 | 3.85 | 7.5 | 8.5 | 10.4 | |
Refrigerating capacity-W | L25 | 100 | 200 | 300 | 400 |
L35 | 110 | 230 | 330 | 440 | |
Rated input power-W | L25 | 168 | 336 | 384 | 480 |
L35 | 184 | 360 | 408 | 500 | |
Heating-W | 250 | 500 | 650 | 850 | |
Circulating air volume-M3/H | 50 | 70 | 100 | 100 | |
Noise-dB(A) | 55 | 57 | 60 | 60 | |
Working environment temperature | -20℃-50℃ | -20℃-50℃ | -20℃-50℃ | -20℃-50℃ | |
Mechanical parameters | |||||
Mount method | Side mounted | Side mounted | Side mounted | Side mounted | |
Height-MM | 281 | 400 | 530 | 530 | |
Width-MM | 185 | 180 | 430 | 430 | |
Thickness-MM | 179.9 | 190.9 | 220 | 220 | |
Controller parameters | |||||
Working voltage (V) | DC48V/50Hz | ||||
Working environment | -30℃~+70℃,<90%RH | ||||
The temperature control precision-℃ | 0.1 | 0.1 | 0.1 | 0.1 | |
Power consumption-W | 5 | 5 | 5 | 5 | |
Communication mode | Dry contact/RS485/RS232/GPRS varies of communication mode are optional |
The General view of the 100w-400w Peltier TEC Cooler:
The photo of the 300w Peltier TEC cooler:
Factory photo:
Contact detail:
Company Profile
Tianjin Yanxiang Electronic Science and Technology Co., Ltd, founded in 2001, is a high-tech company which combined R&D, produce and sale together. The main business scope include heat exchanger, heat exchanger communication cabinet, air conditioner battery cabinet, small outdoor integrated communication base station, network communication cabinet, controller, transducer and other related products. We also offer High and new technology consulting and transfer services. Our products have been sold to Europe, America, Southeast Asia and all over the world. It is also a qualified supplier for well-known domestic enterprises, such as Huawei Technology Company, Tianjin Broadcasting Network System, TT&C Network of China, some Communication Department of Liberation Party, and China Communications. We treat technology innovation as the guidance, do our best to satisfy customers design demand, and win the trust of customers by our high quality products and good after-sales service.
Our company passed ISO9001 Quality System Certification in 2004, and acquired many high-tech achievements and patented technologies. Many of its projects are listed as national and Tianjins key science and technology projects. Besides, It achieved China science and technology private enterprise innovation award, won the Tianjin outstanding enterprise title. Being in the technology industry leading position, we are honored as high-tech private enterprise with vitality and credible by foreign and domestic media.
Our Enterprise tenet is, it is not only to provide products, but also to provide personalized product design and technology project solution for customers. Welcome to contact us for more information.
