Home > Products > Cutting torch > Gas Cutting Torch, Propane Cutting Torch for CNC Cutting Machine
Gas Cutting Torch, Propane Cutting Torch for CNC Cutting Machine
US$ 48 - 66
/ Piece
1 Piece(Min. Order)
- Shanghai
- T/T Credit Card
You May Like
-
Cutting Machine Torch of Cutting Machine With LPG Gas
-
Length 300mm CNC Flame Cutting Torch , Welding Torch
-
Oxy-Fuel Flame Cutting Torch (250mm) for CNC Flame Cutting Machine
-
Oxy-Fuel Flame Cutting Torch (Od 32mm) for CNC Flame Cutting Machine
-
Oxy-fuel Flame Cutting Torch , Cutting Machine Torch for CNC Flame Cutting Machine
-
Heating Torch for Flame Processor of CNC Cutting Machine Plasma Cutting Torch
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Longteng | |
| Model Number | LT-GJ-SK-01 |
Product Description
Specifications
1. gas cutting torch2. For CNC flame cutting machine
3. Out diameter: 32 mm
gas cutting torch , Propane Cutting Torch for CNC Cutting Machine
1) Quick Detail:
1. cutting torch propane
2. For CNC flame cutting machine
3. Balanced pressure structure design cutter to cut the steel plate
2) Description:
1. cutting torch propane is made of high quality forging brass.
2. Balanced pressure structure design.
3. cutting torch propane adopts silver solder, which can effectively avoid leakage.
4. O.D.of the tube: 30 mm and 32mm.
5. The length of the tube: 180mm,250mm,300mm,370mm,450mm.
6. The gear rack can be installed at 4 different positions with 90 degrees between two positions.
7. cutting torch propane is suitable for balanced pressure cutting nozzle/tip with cone of 30 degrees.
3) Applications:
cutting torch propane is suitable for use in digital control flame cutting machines, and is used to connect the cutting nozzles/tips, cutting steel and other metal materials. gas cutting torch is the main tool of gas cutting machine, also known as the torch. The fuel gas and oxygen mixture in the cutting torch, in the form of heat and has a preheating flame shape, in center of the preheating flame, the high pressure oxygen flow is injected for flame cutting work.
During the cutting process, cutting torch propane is used to heat metal to its kindling temperature, and each cutting torch has three valves to control the gas, two blue valves for oxygen, one red valve for fuel gas. From Left to Right for each is the preheating oxygen, the cutting oxygen, the fuel gas.
cutting torch propane needs to match with the cutting tip for cutting, and the different type of cutting tip uses for cutting different thickness of the steel plate. According to different height of the CNC flame cutting machine, the clients will choose the different length oxy-fuel cutting torch.
4) Specifications:
Thimble Length(mm) | Cutting Thickness(mm) | Rack Length/Modulus | Acetylenecutting tips | Propane cutting tips | Inlet connection |
370 | 300 | 210/1 | G02#0-#5 | G03#0-#5 | M16*1.5 |
5)Competitive Advantage:
1.Angle adjustment set simple, beautiful and elegant exterior design.
2.Surface treatment: smooth and beauty
3. 100% inspection on critical dimensions with high accuracy +/-0.01-0.005mm
6)Factory Advantage:
1. Professional manufacturer for CNC Cutting Machine Accessories
2. More than 16 years experience
3. Factory direct price and on time delivery
4. Secure Ordering and worldwide delivery
5. Sample available
6. Small quantity acceptable
7. OEM workable
7) Company Show:
8) Certificates:
