10/100M Ethernet Fiber Media Converter
Description
1.10/100M dual fiber series Media Converters can convert Optical-Electric Ethernet signals between 10/100M UTP interface (TX) and 100M optical fiber interface (FX).
2.It can extend traditional 10/100M fast Ethernet to the distance of 120km through optical fiber link. It possesses stable performance and good quality by adopting latest IC packages from USA and Taiwan. 6 Group LED indicated lights could fully monitor the working conditions of Converters. It is easy for end-users to observe network operation. GT series external power supply Converters could be used alone, or inserted to 14 slots Converters Rack supplied by G.T Crop. suitable for the use of Network Centre.
1.10/100M dual fiber series Media Converters can convert Optical-Electric Ethernet signals between 10/100M UTP interface (TX) and 100M optical fiber interface (FX).
Technical Specification
| 10/100M Dual fiber | ||||||
| Connector | SC/ST | SC | SC | SC | SC | SC |
| Fiber Type | Multi-mode | Single-mode | Single-mode | Single-mode | Single-mode | Single-mode |
| Wavelength | 850/1310nm | 1310nm | 1310nm | 1310nm | 1550nm | 1550nm |
| Distance | 2Km | 25Km | 40Km | 60Km | 80Km | 100Km |
| Min TX PWR | -20.0dBm | -15.0dBm | -8.0dBm | -3.0dBm | -10.0dBm | -6.0dBm |
| Max TX PWR | -12.0dBm | -7.0dBm | -3.0dBm | 1.0dBm | -5.0dBm | -1.0dBm |
| Sensitivity | -31.0dBm | -32.0dBm | -33.0dBm | -36.0dBm | -35.0dBm | -36.0dBm |
| Link Budget | 11.0dBm | 15.0dBm | 25.0dBm | 33.0dBm | 25.0dBm | 30.0dBm |
| 10/100/1000M dual fiber | |||||
| Connector type | SC | SC | SC | SC | SC |
| Fiber type | Multi-mode | Single-mode | Single-mode | Single-mode | Single-mode |
| Wavelength | 850nm | 1310nm | 1310nm | 1550nm | 1550nm |
| Max Distance | 62.5µm: 224m | 20Km | 40Km | 60Km | 80Km |
| 50µm: 550m | |||||
| Min TX PWR | -11.0dBm | -9.0dBm | -4.0dBm | -8.0dBm | -3.0dBm |
| Max TX PWR | -6.0dBm | -5.0dBm | 0dBm | 0dBm | 0dBm |
| Sensitivity | < -18dBm | < -21dBm | < -24dBm | < -25dBm | < -25dBm |
| Link Budget | 7.0dBm | 12.0dBm | 20.0dBm | 17.0dBm | 22.0dBm |
| 10/100/1000M Single fiber | ||||
| Connector type | SC | SC | SC | SC |
| Fiber type | Single-mode | Single-mode | Single-mode | Single-mode |
| Wavelength | 1310/1550nm | 1310/1550nm | 1310/1550nm | 1490/1550nm |
| Max Distance | 20Km | 40Km | 60Km | 80Km |
| Min TX PWR | -10.0dBm | -4.0/-8dBm | 0/-5.0dBm | -1dBm |
| Max TX PWR | -4.0dBm | 0dBm | 3/0dBm | 3dBm |
| Sensitivity | < -22dBm | < -25dBm | <-25dBm | < -25dBm |
| Link Budget | 12.0dBm | 20/17dBm | 25/20dBm | 24.0dBm |
Packing
Company Show
We specialzeid in this field for several years, with best quality, best service and competitive price, and we are 12th yea Alibaba Gold Supplier, providing coaxial cable, lan cable, telephone cable, electrical cable, computer power cable, fiber optical cable or pacth cord, USB cable, hdmi cable, VGA Cable, and other commmunication cables.
More service we can provide:
1.Professional Free Design
2. OEM Support
3. Low MOQ
4. Fast Delivery
5.Free sample.
