Help CenterInduction Cooker Fan
US$ 0.4 - 0.6
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Housing Material:
Plastic
Certification:
CE
Power (W):
10
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Super Silent Micro 5v dc Fan 25*7mmUS$ 0.65 - 1.5MOQ: 1000 Pieces -
Micro dc Brushless Fan 5v 12v 20*10mmUS$ 2 - 2.5MOQ: 1000 Pieces
-
Super Silent Mini dc Fan 3v 5v 12vUS$ 0.5 - 1.5MOQ: 1000 Pieces
-
Low Noise Waterproof Small dc Fan 5v 12vUS$ 0.5 - 0.7MOQ: 1000 Pieces
-
Noiseless 5v dc Fan 25*25*10mmUS$ 0.5 - 0.7MOQ: 1000 Pieces
Housing Material
Plastic
Certification
CE
Power (W)
10
Voltage (V)
18
Model Number
ST12025HS
Brand Name
son times
Place of Origin
Guangdong, China
Specifications
1.dimension:120*120*25mm2.material:PBT
3.rated voltage:12v24v48v
4.sleeve/dual bearing
5.max airflow:90cfm
| Frame size(mm) | 120*120*25mm |
| Bearing type | ball bearing/sleeve |
| Rated voltage | 12/24v/48v |
| Rated speed | 1800-2200RPM |
| Max air flow | 75-90CFM |
| Max pressure | 0.14-0.20inch-H2O |
| Max noise | 29-33dBA |
| Functions | by impedance,FG |
| Safety approvals | CE ROHS |
| Dielectric Strength | 5mA max at 1500VAC for 1 min between lead wire and frame |
| Insulation resistance | 100M ohm between lead wire and frame(DC 500V) |
| Life expectancy(ball bearing) | 70000hrs min at 40 degree C/L10 relative humidity 65%+/-20% |
| Life expectancy(hypro bearing) | >40000hrs min at 40 degree C/L10 relative humidity 65%+/-20% |
| Operation temperature | -10~80 degree C(+14~176 degree F) |
| Storge temperature | -40~75 degree C(-40~167 degree F) |
| Protection | Motor protection and polarity protection |
| Lead wire | UL1571 AWG26,28; UL1007 AWG26,28; UL1061 AWG30 |
| fan blade material | Black PBT (UL94V-0) glass filled |
| frame material | PBT |
| Weight | 140g |
Induction cooker fan
