Specifications
All purpose Indoor Fiber Optic Cable priceIndoor level and vertical laying.
Ceiling laying surface laying etc.
12~144 core All purpose indoor cable distribution/breakout cable
1,We are the manufacture
2,Outdoor/Indoor fiber optic cable. Multi/Single mode fiber
3,High strength kevlar yarn member
4,High quality tight buffered or loose tube
5,ISO9001:2008 &ROHS Compliance.
Description:
Indoor fiber cables use a sheath made from a LSZH/PVC material with the diameter depending on the type of cable. Indoor cables come with dry insulation and the cores possess a buffer of 900µm or 2.4mm. Depending on the customer’s demands, the cables can be fitted with single mode (9/125) or multi mode(50 or 62,5/125 or 10G) cores.
Outdoor cables use a sheath made from polyethylene LLDPE with the diameter depending on the type of cable. Outdoor cables come with dry or wet insulated tubing and the cores are surrounded by a hydro fob gel. Depending on the customer’s demands, the cables can be fitted with single mode (9/125) or multi mode(50 or 62,5/125 or 10G) cores.
This group of cables is strengthened using a glass core and shielding in the form of metal or metal netting.
| Application | Characteristics | |||||||||
| Indoor level and vertical laying. | Multi cable design. | |||||||||
| Ceiling laying surface laying etc. | multi cable with independent strength member. | |||||||||
| Connected to connectors of various models interconnect. | Non-metal central strength member. | |||||||||
| Fiber Counl:12~144 | ||||||||||
| Technical Parameters: | |||||||||||
| Cable Count | Outside Diameter |
Tight buffer Diameter |
Weight | Minimum allowable Tensile Strength (N) |
minimum allowable Crush Load (N/100mm) |
Minimum Bending Radius (MM) |
Storage temperature |
||||
| (MM) | (MM) | (KG) | short term | long term | short term | long term | short term | long term | (°C) | ||
| 12 | 15.5 | 0.9 | 205.00 | 1500 | 500 | 1500 | 600 | 20D | 10D | -20+60 | |
| 24 | 15.5 | 0.9 | 205.00 | 1500 | 500 | 1500 | 600 | 20D | 10D | -20+60 | |
| 36 | 17.5 | 0.9 | 255.00 | 1500 | 500 | 1500 | 600 | 20D | 10D | -20+60 | |
| 48 | 17.5 | 0.9 | 255.00 | 1500 | 500 | 1500 | 600 | 20D | 10D | -20+60 | |
| 60 | 19.5 | 0.9 | 320.00 | 1500 | 500 | 1500 | 600 | 20D | 10D | -20+60 | |
| 72 | 19.5 | 0.9 | 320.00 | 1500 | 500 | 1500 | 600 | 20D | 10D | -20+60 | |
| 96 | 22.0 | 0.9 | 395.0 | 1500 | 500 | 1500 | 600 | 20D | 10D | -20+60 | |
| 144 | 28.0 | 0.9 | 597.0 | 1500 | 500 | 1500 | 600 | 20D | 10D | -20+60 | |
