Specifications
Razor wire fence1.Type bto-22
2.Surface treatment: hot dip galvanized
3.Structure: welded razor wire mesh
4.ISO9001
BTO-22 galvanized razor wire welded mesh fence
Razor wire is the most popular high security fencing for military and high grade residence safety.
Razor Blade type: Long blades, short blades and medium sized blades.
Razor barbed wire material: electro galvanized, hot dipped galvanized or stainless steel.
Razor barbed wire form : straight line, crossed coil razor wire, single coil concertina razor wire, flat wrap razor wire.
Straight type razor barbed wire is straightened from spiral razor barbed wire. It is easy to be installed while saving the cost.
Spiral razor barbed wire is installed without clips, it can be installed in its natural loops on walls, which looks beautiful and practical.
Crossed razor barbed wire is made of two pieces of razor wire, which is buttoned by the heavy clips. It can be made into different crossed type in different diameter and widely used in high wall or bounding wall, it has good effect on insulating and protecting.
Flat razor barbed wire coil is the new application for razor wire. It is practicable and beautiful. It can be used together with the straight type razor barbed wire to form protecting wall. Razor barbed wire in flat wrap type is mainly used in warehouse, stock farm, farm, mine, prison, national defense, etc.
Razor Blade Specification | ||||||
Reference Number |
Blade Style |
Thickness |
Wire Dia |
Barb |
Barb |
Barb |
BTO-10 |
|
0.5±0.05 |
2.5±0.1 |
12±1 |
13±1 |
26±1 |
BTO-12 |
|
0.5±0.05 |
2.5±0.1 |
12±1 |
15±1 |
26±1 |
BTO-18 |
|
0.5±0.05 |
2.5±0.1 |
18±1 |
15±1 |
33±1 |
BTO-22 |
|
0.5±0.05 |
2.5±0.1 |
22±1 |
15±1 |
34±1 |
BTO-28 |
|
0.5±0.05 |
2.5±0.1 |
28±1 |
15±1 |
34±1 |
BTO-30 |
|
0.5±0.05 |
2.5±0.1 |
30±1 |
18±1 |
34±1 |
CBT-60 |
|
0.6±0.05 |
2.5±0.1 |
60±2 |
32±1 |
96±2 |
CBT-65 |
|
0.6±0.05 |
2.5±0.1 |
65±2 |
21±1 |
100±2 |
Barbed Tape Wire Specification | ||||
Loop Outside Diameter |
No. of Loops |
Standard Length per Coil |
Type |
Notes |
450mm |
33 |
7-8M |
CBT-60.65 |
Single coil |
500mm |
56 |
12-13M |
CBT-60.65 |
Single coil |
700mm |
56 |
13-14M |
CBT-60.65 |
Single coil |
960mm |
56 |
14-15M |
CBT-60.65 |
Single coil |
450mm |
56 |
8-9m(3 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
500mm |
56 |
9-10M (3 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
600mm |
56 |
10-11M(3 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
600mm |
56 |
8-10M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
700mm |
56 |
10-12M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
800mm |
56 |
11-13M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
900mm |
56 |
12-14M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
960mm |
56 |
13-15M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
980mm |
56 |
14-16M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
