Specifications
Wire gauge BWG8-BWG36Hot dipped galvanized surface treatment
straight cut wire, loop tie wire, U type wire
binding wire coil
Galvanized Iron Wire
Galvanized iron wire can be classified into hot-dipped galvanized iron wire and electro galvanized wire according to the differences of processing. Sizes of hot-dipped galvanized wire: 8# to 36# (wire diameter ranging from 3.8mm to 0.19mm)
Sizes of electro galvanized wire: 8# to 38# (wire diameter ranging from 3.8mm to 0.15mm)
Galvanized Wire gauge: Standard wire gauge from 8# to 16#
Galvanized iron wire is made with mild steel, hard-drawn, then galvanized. It is rust-resistant and very versatile in applications. Galvanized iron wire can be supplied in the form of coil wire, spool wire or further processed into straightened cut wire or U type wire.
Application: Galvanized iron wire is mainly used in construction as binding wire, express way fencing as fencing wire, binding of flowers as wire ties in the garden and yard, and in weaving of wire mesh.
Hot Dipped Galvanized Iron Wire:
Production Process of Hot-dipped Galvanized Iron Wire: Steel rod coil -- Wire Drawing --Annealing -- Rust Removing -- Acid Washing -- Zinc Plating -- Wire Coiling.
Hot-dip Galvanized Iron Wire, also known as hot-dip zinc-plated iron wire, or thermally galvanized iron wire. We produces hot-dipped galvanized iron wire at diameter from 0.19mm to 25.0mm, which can be supplied in the form of coil wire, spool wire, etc.
Technical Data:
Galvanized wire | |||
wire gauge size |
SWG(mm) |
BWG(mm) |
metric(mm) |
8 |
4.06 |
4.19 |
4.00 |
9 |
3.66 |
3.76 |
- |
10 |
3.25 |
3.40 |
3.50 |
11 |
2.95 |
3.05 |
3.00 |
12 |
2.64 |
2.77 |
2.80 |
13 |
2.34 |
2.41 |
2.50 |
14 |
2.03 |
2.11 |
- |
15 |
1.83 |
1.83 |
1.80 |
16 |
1.63 |
1.65 |
1.65 |
17 |
1.42 |
1.47 |
1.40 |
18 |
1.22 |
1.25 |
1.20 |
19 |
1.02 |
1.07 |
1.00 |
20 |
0.91 |
0.89 |
0.90 |
21 |
0.81 |
0.813 |
0.80 |
22 |
0.71 |
0.711 |
0.70 |
Electro Galvanized Iron Wire:
Electro Galvanized Iron Wire is also known as electric galvanized iron wire or galvanized steel wire. Electric galvanized wire diameter ranging from 0.14mm to 5.0mm, which can be supplied in the form of coils, spools, U type wire or straight cut wire. Electric Galvanized Iron Wire production processes: steel rod coil, wire drawing, annealing, rust removing, acid washing, boiling, drying, zinc feeding to wire coiling.
Electro Galvanized Iron Wire Size: Electro galvanized iron wire ranging from 6# to 38#, it is widely used by users.
Electro Galvanized Iron Wire Feature: firm zinc coating, evenly plated and smooth and bright surface etc.
