Stainless Steel Wire Mesh Decking
US$ 9 - 25
MOQ: 30 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Material:
Other, Stainless Steel Wire or Galvanized Steel Wire
Type:
Welded Mesh
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Iron Wine Shelf/Wine Rack/Metal Wine HolderUS$ 10 - 20MOQ: 50 Pieces -
Top Grade Fashion Metal Stainless Steel Wine Wire ShelfUS$ 10 - 20MOQ: 50 Pieces
-
Stainless Steel Decorative Wine HoderUS$ 10 - 20MOQ: 50 Pieces
-
Stainless Steel Decorative Wine ShelfUS$ 10 - 20MOQ: 50 Pieces
-
Stainless Steel Wine Wire HoldersUS$ 10 - 20MOQ: 50 Pieces
Place of Origin
Hebei, China
Material
Other, Stainless Steel Wire or Galvanized Steel Wire
Type
Welded Mesh
Application
Other, wire mesh trays
Weave Style
Plain Weave
Wire Diameter
4mm 5mm 5.3mm 5.5mm 6mm
Technique
Welded Mesh
Model Number
WMD-2.5-4.5
Brand Name
He Xing
Stainless Steel Wire Mesh Decking
Wire mesh deck is made from round steel wire of diameter 4mm, 5mm or 6mm.
Matched with cross bars to enhance the load capacity. Cross bars are the main objects taking loads. The load capacity of wire mesh deck is 300kg to 2000kg, or 500-5,000 lbs. Mesh of wire mesh deck can be 100mmx50mm, 100mmx25mm, 50mmx50mm and 50mmx25mm. The most used is 100mm x 50mm. The width of wire mesh deck ranges from 800mm to 1350mm. The depth of Wire mesh deck is decided by the depth of deck frame.
| WIRE MESH DECK ( epoxy finish) | ||||||||||
| ITEMS | inch (D*W) | 50*100*Ø5.5mm | Unit price | 50*100*Ø6.0mm | Unit price | Container | ||||
| Load: 3500LBS | kg | lbs | USD | kg | lbs | USD | 20ft | 40ft | ||
| 1 | HX42-4-35 | 42"*35" | 11.85 | 26.1 | 13.03 | 13 | 28.6 | 14.30 | 900 | 1950 |
| 2 | HX42-5-48 | 42"*48" | 15.2 | 33.5 | 16.66 | 16.7 | 36.8 | 18.37 | 750 | 1450 |
| 3 | HX48-4-35 | 48"*35" | 13.4 | 29.5 | 14.74 | 14.7 | 32.4 | 16.17 | 700 | 1450 |
| 4 | HX48-5-48 | 48"*48" | 17.2 | 37.9 | 18.91 | 18.9 | 43.0 | 20.82 | 550 | 1100 |
| 5 | HX24-3-35 | 24"*35" | 7.0 | 15.5 | 7.65 | 7.7 | 17.0 | 8.47 | 1400 | 3000 |
| 6 | HX24-3-48 | 24"*48" | 8.2 | 18.1 | 9.03 | 9.2 | 20.3 | 10.12 | 1100 | 2100 |
| 7 | HX30-3-48 | 30"*48" | 9.7 | 21.4 | 10.71 | 10.9 | 24.0 | 11.99 | 750 | 1500 |
| 8 | HX36-3-35 | 36"*35" | 9.5 | 21.0 | 10.43 | 10.5 | 23.1 | 11.55 | 900 | 2100 |
| 9 | HX36-3-48 | 36"*48" | 11.3 | 24.9 | 12.47 | 12.7 | 28.0 | 13.97 | 700 | 1400 |
| 10 | HX42-4-35 | 42"*35" | 11.8 | 26.0 | 13.02 | 13.0 | 28.6 | 14.30 | 880 | 2100 |
| 11 | HX42-5-48 | 42"*48" | 15.0 | 33.0 | 16.50 | 16.7 | 36.8 | 18.37 | 700 | 1580 |
| 12 | HX48-4-35 | 48"*35" | 13.4 | 29.5 | 14.74 | 14.7 | 32.4 | 16.17 | 700 | 1580 |
| 13 | HX60-5-35 | 60"*35" | 24.7 | 54.4 | 27.21 | 500 | 900 | |||
| 14 | HX60-5-48 | 60"*48" | 28.6 | 63.0 | 31.42 | 400 | 750 | |||
| WIRE MESH DECk(load: 1500LBS) | ||||||||||
| ITEMS | inch(D*W) | 63*114*Ø5.5mm | Unit price | 63*114*Ø6.0mm | Unit price | Container | ||||
| Load:1500LBS | kg | lbs | USD | kg | lbs | USD | 20ft | 40ft | ||
| 1 | HX36-3-46 | 36"*46" | 10.2 | 22.5 | 11.22 | 12.2 | 26.9 | 13.42 | 900 | 1800 |
| 2 | HX36-3-52 | 36"*52" | 10.8 | 23.8 | 11.88 | 12.9 | 28.4 | 14.19 | 700 | 1400 |
| 3 | HX42-3-46 | 42"*46" | 11.8 | 26 | 12.98 | 13.1 | 28.9 | 14.41 | 950 | 1800 |
| 4 | HX42-3-52 | 42"*52" | 12.5 | 27.5 | 13.75 | 13.9 | 30.6 | 15.29 | 700 | 1400 |
| 5 | HX44-3-46 | 44"*46" | 12.2 | 26.9 | 13.42 | 13.4 | 29.5 | 14.74 | 800 | 1600 |
| 6 | HX44-3-52 | 44"*52" | 12.9 | 28.4 | 14.19 | 14.3 | 31.5 | 15.73 | 650 | 1300 |
| 7 | HX48-3-46 | 48"*46" | 13.2 | 29.1 | 14.52 | 14.5 | 31.9 | 15.95 | 800 | 1600 |
| 8 | HX48-3-52 | 48"*52" | 13.9 | 30.6 | 15.29 | 15.5 | 34.2 | 17.05 | 500 | 1000 |
| 9 | HX36-4-58 | 36"*58" | 12.9 | 28.4 | 14.19 | 14.2 | 31.3 | 15.62 | 700 | 1400 |
| 10 | HX42-4-58 | 42"*58" | 14.7 | 32.4 | 16.17 | 16.2 | 35.7 | 17.82 | 650 | 1300 |
| 11 | HX48-4-58 | 48"*52" | 16.7 | 36.8 | 18.37 | 18.5 | 40.8 | 20.34 | 460 | 1000 |
