Specifications
125 150 250 350 450 500 700Material SS304 304L 316;
Al Copper Carbon Steel Ti
height 50-200mm
tower diameter more than 1.5m
Tower Packing Copper/ Stainless Steel Product Details:
Tower Packing Copper/ Stainless Steel is the most efficient packing widely applied all over the world currently. Tower packing copper/ stainless steel material is one kind of disc-shaped packing made from parallel and straight line of metal corrugated plate. The dip angle between axes and corrugation is 30 degree or 45 degree. Adjacent two pieces of corrugated plates are in the opposite direction.
| Model No. | peak height mm | specific surface area m²/m³ | Accumulation weight Kg/m³ |
voidage m³/m³ |
pressure drop Pa/n | HETP /mm | No. of theoretical plates m-1 | F factor m/s(Kg/m³)0.5 |
| 250X | 12 | 250 | 125 | 95 | 10-40 | 100 | 2.5-3 | 2.5-3.5 |
| 500X | 6.5 | 500 | 250 | 90 | 40 | 200 | 4-5 | 2.0-2.4 |
| 700Y | 4.5 | 700 | 350 | 85 | 67 | 400-333 | 8-10 | 1.5-2.0 |
X-250: Metal Wire Gauze Tower Packing is applied in the minutely rectifying of big production, low theoretical plates.
X-500: Metal Wire Gauze Tower Packing is applied in the vacuum rectifying of thermosensitive, hard decomposition. Especially under the pressure of 7Kpa.
Y-700: Metal Wire Gauze Tower Packing is applied in the separation of isomeric compound.
