Home > Construction & Decoration > Decoration Materials > Sandwich Panel > Galvanized/Stainless Steel Steel Grating Stair Tread

Galvanized/Stainless Steel Steel Grating Stair Tread

Name: Galvanized/Stainless Steel Steel Grating Stair Tread
Brand: Hexing
SKU: 100820485

Galvanized/Stainless Steel Steel Grating Stair Tread thumbnail-1

Galvanized/Stainless Steel Steel Grating Stair Tread photo-1

US$ 25 - 50 MOQ: 1 Square Meter

Key Specifications

Get Latest Price

Place of Origin:

Hebei, China

Brand Name:

Hexing

Model Number:

G505/40/100

Contact Supplier Request Quote Chat Now

Anping County Hexing Wire Product Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin Port China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hebei, China

Brand Name Hexing

Model Number G505/40/100

Material Galvanized Sheet

Specifications

Steel Grating Stair Tread
Cross bar's centre 50 100
Load bar's centres 30 40 50mm
Bar Thick 5-20 mm
Load Bar Width 65-200 mm

Galvanized/Stainless Steel Steel Grating Stair Tread

Steel gratings are extremely versatile with various materials of galvanized steel, stainless steel, aluminum alloy, fiberglass.

Steel Grating Specification:
Load Bar Size: 20x3mm-75x8mm generally.
Load bar's c/c distance: 30mm, 40mm, 60mm and 12.5mm or 33.5mm and their multiples generally.
Cross bar's c/c distance: 50mm, 100mm, 38mm, 76mm generally.
Cross bar's size: 6mmx6mm twisted rod generally;
small size grating using 5mmx5mm twisted rod;
For stainless using diam 5mm round bar.
Load bar's top surface: Flat type-F, Serrated type-S, I type

Series	Load bar's c/c distance	Cross bar's c/c distance	Load Bar Specifications (Width x Thickness)
Series	Load bar's c/c distance	Cross bar's c/c distance	20×3	25×3	32×3	40×3	20×5	25×5
1	30	100	G203/30/100	G253/30/100	G323/30/100	G403/30/100	G205/30/100	G255/30/100
1	30	50	G203/30/50	G253/30/50	G323/30/50	G403/30/50	G205/30/50	G255/30/50
2	40	100	G203/40/100	G253/40/100	G323/40/100	G403/40/100	G205/40/100	G255/40/100
2	40	50	G203/40/50	G253/40/50	G323/40/50	G403/40/50	G205/40/50	G255/40/50
3	60	50	-	G253/60/50	G253/60/50	G403/60/50	G205/60/50	G255/60/50
Series	Load bar's c/c distance	Cross bar's c/c distance	Load Bar Specifications (Width x Thickness)
Series	Load bar's c/c distance	Cross bar's c/c distance	32×5	40×5	45×5	50×5	55×5	60×5
1	30	100	G325/30/100	G405/30/100	G455/30/100	G505/30/100	G555/30/100	G605/30/100
1	30	50	G325/30/50	G405/30/50	G455/30/50	G505/30/50	G555/30/50	G605/30/50
2	40	100	G325/40/100	G405/40/100	G455/40/100	G505/40/100	G555/40/100	G605/40/100
2	40	50	G325/40/50	G405/40/50	G455/40/50	G505/40/50	G555/40/50	G605/40/50
3	60	50	G325/60/50	G405/60/50	G455/60/50	G505/60/50	G555/60/50	G605

Series 1: 30mm centre distance
Load bar's centre distance 30mm, cross bar's centre distance 100mm; Load bar's centre distance 30mm, cross bar's centre distance 50mm.
Suitable for heavy loading
Available in mild steel (forge welded or twistlock) and aluminium (twislock)

Series 2: 40mm centre distance
Load bar's centre distance 40mm, cross bar's centre distance 100mm; Load bar's centre distance 40mm, cross bar's centre distance 50mm.
Series 2 grating is available in both forge bar and twistlock. The lightweight, economical design of the Series 2 grating makes it perfect for walkways, fixed platforms, stairways and ladders. Available in twistlock (mild steel and aluminium material)

Series 3: 60mm centre distance
Load bar's centre distance 60mm, cross bar's centre distance 100mm; Load bar's centre distance 60mm, cross bar's centre distance 50mm.
Series 3 grating is mainly used in the mining industry as it minimises the build-up of spillages on the flooring. The openings let small matter fall through while larger matter is caught on the grating. Series 3 is a very lightweight design and is not recommended for high-impact load.

Characteristics: High strength, light structure; beautiful appearance, durable; ventilation, lighting, heat dissipation, explosionproof, corrosion resistance, good performance of skidproof.

Applications: Steel grating are widely used as platform, pavement, trestle, drain cover, manhole cover, ladder, fencing in field of petrochemical engineering, power plant, water plant, sewage treatment plant, municipal engineering, environmental engineering etc.
