Help CenterAluminum Alloy Decorative Steel Wire Rope Mesh
Related Products
-
Magnesium Aluminium Alloy Decorative Rod and Rope NettingUS$ 15 - 60MOQ: 50 Square Meters -
Decorative Wire NettingUS$ 15 - 60MOQ: 50 Square Meters
-
Stainless Steel Decorative Wavy NettingUS$ 15 - 60MOQ: 50 Square Meters
-
Stainless Steel Security Window Mesh/anti-theft MeshUS$ 15 - 40MOQ: 100 Square Meters
-
Black Coated Stainless Steel Security Anti-theft Screen MeshUS$ 15 - 40MOQ: 100 Square Meters
Specifications
Decorative steel wire rope mesh1. Pitch 4-10mm
2. Rope diameter 0.6-3.0mm
3. Rod diameter 0.6--5mm
4. Manufacture
Aluminum alloy decorative steel wire rope mesh
Aluminum alloy decorative rod and rope netting is a new type of building decoration materials, which is widely applied to Building facade, partition, sunshade, balcony and corridor. Aluminum alloy decorative rod and rope netting has the advantages of nonflammability, High strength, strong, easy to maintenance, vivid decorative effect and makes an effect of protection for architectural structure.
Specifications are as per clients' requirement.
Pitch: 4mm-10mm
Rope diameter: 0.6mm-3.0mm
Rod diameter: 0.6mm-5mm
Material: Aluminum alloy
Type |
rope(mm) |
c/c of rope(mm) |
rod(mm) |
c/c of rod(mm) |
weight(kg/sqm |
Material |
HX--1706 |
1.6 |
3.2 |
1.2 |
6 |
5 |
304/316/316L |
HX--1720 |
2 |
3.1 |
5 |
5.2 |
10.2 |
304/316/316L |
HX—4225 |
2.4 |
6 |
2.5 |
8 |
11 |
304/316/316L |
HX--4252 |
2.5 |
5 |
2 |
6 |
12.17 |
304/316/316L |
HX--4510 |
3 |
5 |
3 |
10 |
17.15 |
304/316/316L |
HX--4525 |
2.5 |
6 |
2 |
8 |
9.8 |
304/316/316L |
HX—2610 |
0.6 |
2.54 |
0.6 |
2.54 |
1.8 |
304/316/316L |
HX—4185 |
1.8 |
4 |
1.5 |
5.5 |
7.74 |
304/316/316L |
