Specifications
Decorative rod and rope nettingPitch: 4mm-10mm
Rope diameter: 0.6mm-3.0mm
Rod diameter: 0.6mm-5mm
Stainless steel, Aluminum
Decorative rod and rope wire netting
Decorative rod and rope wavy netting is a new type of building decoration materials, which is widely applied to Building facade, partition, sunshade, balcony and corridor. Decorative rod and rope wavy netting has the advantages of nonflammability, High strength, strong, easy to maintenance, vivid decorative effect and makes an effect of protection for architectural structure.
Specifications are as per clients' requirement.
Pitch: 4mm-10mm
Rope diameter: 0.6mm-3.0mm
Rod diameter: 0.6mm-5mm
Material: Aluminum alloy, copper, galvanized, magnesium aluminium alloy, Stainless steel, steel, iron etc.
Type |
rope(mm) |
c/c of rope(mm) |
rod(mm) |
c/c of rod(mm) |
weight(kg/sqm |
Material |
HX--1706 |
1.6 |
3.2 |
1.2 |
6 |
5 |
304/316/316L |
HX--1720 |
2 |
3.1 |
5 |
5.2 |
10.2 |
304/316/316L |
HX—4225 |
2.4 |
6 |
2.5 |
8 |
11 |
304/316/316L |
HX--4252 |
2.5 |
5 |
2 |
6 |
12.17 |
304/316/316L |
HX--4510 |
3 |
5 |
3 |
10 |
17.15 |
304/316/316L |
HX--4525 |
2.5 |
6 |
2 |
8 |
9.8 |
304/316/316L |
HX—2610 |
0.6 |
2.54 |
0.6 |
2.54 |
1.8 |
304/316/316L |
HX—4185 |
1.8 |
4 |
1.5 |
5.5 |
7.74 |
304/316/316L |
