electro galvanized ranch wire fence

Specifications

Ranch Fence
1. Roll width 0.8m-2.0m
2. Roll length 20m-200m
3. Wire diam: 1.6mm-3.5mm
4. Aperture: 15mm-600mm

electro galvanized ranch wire fence



Ranch wire fence is the  most ideal wire fence for farm and ranch uses.



Opening shape can be square, rectangular or spacing. Ranch wire fences have many weaving types, such as fixed knot fence, hinge knot fence, woven wire fence and chain link field fence. They have a wide range of uses and features.



Classification of wire fence for grassland:

Agricultural fence (such as field fence, livestock panel fence);
Ranch fence (such as sheep & goat fence);
Grassland fence(such as border fence).

Ranch wire fence applications:

Ranch wire fence has been widely used almost covering each corner in our lives. Grassland fences are mainly used as barriers in ranch construction, grazing and feeding of animals in agriculture farm and grassland; Used for protection of natural environment, etc.



Specification	Number of Wire	Roll Width	Wire diameter
			Edge Wire	Middle Weft Wire	Warp Wire
91L 5/70/15	5	700mm	2.8mm	2.5mm	2.5mm
91L 8/110/15	8	1100mm	2.8mm	2.5mm	2.5mm
91L 5/70/30	5	700mm	2.8mm	2.5mm	2.5mm
91L 6/70/30	6	700mm	2.8mm	2.5mm	2.5mm
91L 6/90/30	6	900mm	2.8mm	2.5mm	2.5mm
91L 7/90/30	7	900mm	2.8mm	2.5mm	2.5mm
91L 8/110/30	8	1100mm	2.8mm	2.5mm	2.5mm
91L 5/70/60	5	700mm	2.8mm	2.5mm	2.5mm
91L 6/90/60	6	900mm	2.8mm	2.5mm	2.5mm
91L 6/100/60	6	1000mm	2.8mm	2.5mm	2.5mm
91L 7/90/60	7	900mm	2.8mm	2.5mm	2.5mm
91L 7/100/60	7	1000mm	2.8mm	2.5mm	2.5mm
91L 7/110/60	7	1100mm	2.8mm	2.5mm	2.5mm
91L 8/110/60	8	1100mm	2.8mm	2.5mm	2.5mm
