Bitumen Coated Biaxial/Triaxial Fiberglass Geogrid
US$ 0.15 - 3.55
MOQ: 1000 Square Meters
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
He Xing
Model Number:
TGS-B-40-40
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Low Carbon Steel Checkered PlateUS$ 1,900 - 4,900MOQ: 1 Ton -
Aluminum Checkered PlateUS$ 1,900 - 4,900MOQ: 1 Ton
-
Black Iron Wire Cloth From AnpingUS$ 1 - 10MOQ: 100 Square Meters
-
Black Wire Cloth Filter DiscsUS$ 1 - 10MOQ: 100 Square Meters
-
Black Wire Cloth Factory PriceUS$ 1 - 10MOQ: 100 Square Meters
Place of Origin
Hebei, China
Brand Name
He Xing
Model Number
TGS-B-40-40
Material
Fiberglass
Bitumen Coated Biaxial/Triaxial Fiberglass Geogrid
Fiberglass Geogrid is made from fiberglass or polyester yarn coated with modified asphalt polymer resin, PVC, SBR.
Fiberglass Geogrid Product Function:
Fiberglass Geogrid can be used to reinforce road pavement, railway basement, tunnel, slope and embankment and so on.
Fiberglass Geogrid also has the following characteristics:
(1) High tensile strength in both the warp and weft directions
(2) Low elongation
(3) Excellent temperature range
(4) Good anti-age and alkali-resistance
(5) Reduce construction cost, extend service life of road and prevent deflection cracks.
Fiberglass Geogrid specification and performance parameters (Fiberglass Geogrid self-adhesion):
Performance specifications |
TGS-B-25-25 |
TGS-B-30-30 |
TGS-B-40-40 |
TGS-B-50-50 |
TGS-B-80-80 |
TGS-B-100-100 |
|
strength (KN/m) |
lengthways |
25 |
30 |
40 |
50 |
80 |
100 |
transverse |
25 |
30 |
40 |
50 |
80 |
100 |
|
Elongation at break % |
≤15 |
≤15 |
≤15 |
≤15 |
≤15 |
≤15 |
|
Aperture Size (mm) |
12.5×12.5 12.7×12.7 25×25 25.4×25.4 25.7×25.7 30×30 40×40 50×50 |
||||||
width (m) |
1-6 |
||||||
Performance specifications |
EGA50-50 |
EGA60-60 |
EGA80-80 |
EGA100-100 |
EGA120-120 |
EGA150-150 |
|
strength (KN/m) |
lengthways |
50 |
60 |
80 |
100 |
120 |
150 |
transverse |
50 |
60 |
80 |
100 |
120 |
150 |
|
Elongation at break % |
≤15 |
≤15 |
≤15 |
≤15 |
≤15 |
≤15 |
|
Aperture Size (mm) |
12.5×12.5 12.7×12.7 25×25 25.4×25.4 25.7×25.7 30×30 40×40 50×50 |
||||||
width (m) |
1-6 |
||||||
