6cm*6cm Mesh Stainless Steel 304 Tortoise Shell Mesh/Hexsteel Mesh
US$ 15 - 55
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Material:
Other, stainless steel 304
Type:
Welded Mesh
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hot-dipped Galvanized Tortoise Shell Net/Hexsteel MeshUS$ 15 - 55MOQ: 50 Pieces -
Galvanized Tortoise Shell MeshUS$ 15 - 55MOQ: 10 Pieces
-
Stainless Steel Hexsteel Mesh Flex Metal Refractory LiningUS$ 25 - 45MOQ: 100 Square Meters
-
Galvanized Hexsteel Mesh Metal Refractory LiningUS$ 25 - 45MOQ: 100 Square Meters
-
50mm Hole Low-carbon Hexsteel Mesh for ConstructionUS$ 15 - 55MOQ: 50 Pieces
Place of Origin
Hebei, China
Material
Other, stainless steel 304
Type
Welded Mesh
Application
Other, refractory lining for the petrochemical industry
Weave Style
Other, welding and stamping
Wire Diameter
1mm-3mm thick
Technique
Welded Mesh
Model Number
HX13101616
Brand Name
Hexing
Specifications
Hexsteel Mesh:Pitch distance 20mm-60mm
Mesh thickness 10mm-30mm
Panel thickness 1mm-3mm
Carbon steel; Galvanized; stainless
6cm*6cm Mesh Stainless Steel 304 Tortoise Shell Mesh/Hexsteel Mesh
Hexsteel Mesh Material:
Stainless steel 0Cr13(410S), 1Cr13(410), 0Cr18Ni9(304), 1Cr18Ni9Ti
Carbon steel (A3F)
Galvanized steel
Brass
Hexsteel Mesh specification:
Pitch distance: 20mm-60mm;
Mesh thickness: 10mm-30mm;
Panel thickness: 1mm-3mm;
Connection Type: Inner buckle lock riveting / outer buckle lock riveting.
Hexsteel mesh application:
Tortoise Shell Net is large-scale installed for the petrochemical industry, in particular, is conducive to the catalyst-based device structures lining, as one of the main components, which can improve the wear resistance and strength of the lining, wear-resistant lining is reinforced with the turtle nets, the general part of Carbon Steel (A3F) shells networks, such as the reactor and a secondary cyclone, U-tube regenerator flue gas.
| Tortoise Shell Net Specification | |||
| Item | Type | Description | |
|
0Cr13 hex metal G-01 |
1.75X20X50mm | AS 0Cr13 hex metal, used in 500--600 Celcius, in petrochemical industry | |
|
1Cr13 hex metal G-02 |
1.5X20x50mm | Light hex metal, as dual-layerlining in petrochemical and electric power industry | |
|
1Cr13 hex metal G-03 |
331 | used in thermal power plants, steel mills, chemical refinery project | |
|
Thermostability hex metal G-05 |
1.5X15x50mm | As wear-resisting lining, widely used as two inverter system double-layer liner in petrochemical industry, the circulating fluidized bed boiler cyclone separator in electric power industry | |
|
321 Corrosion-resistant hex metal G-06 |
1.8X20X50mm | As carbon steel hex metal, widely used in raw oil, nitrogenous fertilizer, sulfuric acid circulating fluidized bed boiler of thermal power plant projects | |
|
Light hex metal G-07 |
1.0X10X50mm | Widely used as two inverter system double-layer liner in petrochemical industry, the circulating fluidized bed boiler cyclone separator in electric power industry | |
|
A3 Steel hex metal G-08 |
2.0X20X50mm |
As the framework, welded in inner surface of high temperature and abrasion resistance large diameter, then coating the corundum lining material | |
|
Intensive hex metalG-09 |
2.0X30X30mm | As carbon steel hex metal, widely used in raw oil, nitrogenous fertilizer, sulfuric acid circulating fluidized bed boiler of thermal power plant projects | |
|
Big hole hex metal G-10 |
2.0X20x100mm | As indefinite form lining | |
|
SUS 304 hex metal G-11 |
14#X3/4" X2" | Light hex metal, as dual-layerlining in petrochemical and electric power industry | |
|
Light hex metal G-12 |
LTWH-006 | As the framework, welded in inner surface of high temperature and abrasion resistance large diameter, then coating the corundum lining material | |
