Hexaganal Gabion Mesh, Gabion Box

Specifications

Hexagonal Gabion Mesh
1. Mesh wire diam 2.7mm
2. Edge wire diam 3.4 mm
3. Binding wire 2.2 mm
4. Aperture 80x100mm

Hexaganal Gabion Mesh, Gabion Box



Material: High quality low carbon steel wire, galvanized wire, stainlesss steel wire, PVC coated wire

Weaving: Link and weaving is simple, artistic and practical

Standard: ASTM-975-97 and BS EN 10223-2:1998

Wire diameter: 1.6mm--4mm (mainly according to your requirement)

Mesh Type:  60x80 80x90 80x100 80x120 100x120 100x150 120x150 120x180 180x200

Yearly Output: more than six million square meters



Mesh opening (mm)	Wire diameter (metal wire)   (mm)	Wire diameter  (PVC coated Inner and Outer wire) (mm)	Strands	Size LengthxWidthxHeight (m)
60X80	φ2.0-2.8	φ2.0/3.0-2.5/3.5	3	1. 2mx1mx0.5 m; 2. 2mx1mx1 m; 3. 3mx1mx1m; 4. 4mx1mx1m; 5. 4mx1mx0.5m.
80X100	φ2.0-3.2	φ2.0/3.0-2.8/3.8	3
80X120	φ2.0-3.2	φ2.0/3.0-2.8/3.8	3
100X120	φ2.0-3.4	φ2.0/3.0-2.8/3.8	3
100X150	φ2.0-3.4	φ2.0/3.0-2.8/3.8	3
120X150	φ2.0-4.0	φ2.0/3.0-3.0/4.0	3



Gabion Box
Nominal Dimensions			Number of Cells	Capacity (m³)	Units/Bundle
Length (m)	Width (m)	Height (m)			Zinc	PVC
1,0	1,0	1,0	1	1,0	74	64
1,5	1,0	1,0	1	1,5	74	62
2,0	1,0	1,0	2	2,0	44	38
3,0	1,0	1,0	3	3,0	32	26
4,0	1,0	1,0	4	4,0	24	20
2,0	0,5	0,5	2	0,5	100	80
2,0	1,0	0,5	2	1,0	60	50
3,0	1,0	0,5	3	1,5	40	34
4,0	1,0	0,5	4	2,0	32	30
Binding Wire: Sufficient wire is supplied for lacing and bracing operations.
Tolerances: Height, Width : ±5%;   Length : ±10%

















































Features



•Economic.
•Just fill the stone into the gabions and seal it.
•Simple installation.
•No special technology needed.Weather proof under natural destroy, corrosion resistant.
•No collapse even under big scope of deforming.
•Sludge in the stones is good for plant growing.
•Mixed to form a integrity with the natural environment.Good permeation can prevent the damage by hydrostatic.
•Less transport freight. It can be folded together for transport and further installation.



Gabion Basket Applications



•Control and guide of water or flood
•Flood bank or guiding bank
•Preventing of rock breaking
•Bridge Protection
•Water and soil protection
•Coast protection
•Seaport engineering
•Strengthening structure of soil
•Protection of road
