Good Quality Galvanized Welded Gabion Box
US$ 12 - 29
MOQ: 500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
Hexing
Model Number:
GWGB/3/75x75
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Welded Wire Mesh Gabion Box and MattressUS$ 1.5 - 2.9MOQ: 5 Square Meters -
China Galvanized Welded Gabion BasketUS$ 9 - 39MOQ: 100 Pieces
-
Welded Gabion Basket 50x200mmx6mmUS$ 9 - 39MOQ: 100 Pieces
-
Welded Gabion Mesh 50x200mmx6mmUS$ 9 - 39MOQ: 100 Pieces
-
Welded Gabion Box 50x200mmx6mmUS$ 9 - 39MOQ: 100 Pieces
Place of Origin
Hebei, China
Brand Name
Hexing
Model Number
GWGB/3/75x75
Material
Other, Galvanized Iron Wire, Galvanized Iron Wire
Type
Welded Mesh
Application
Gabions
Hole Shape
Square
Aperture
75mmx75mm
Wire Gauge
3mm
Good Quality Galvanized Welded Gabion Box
Welded wire mesh gabion box and mattresses are supplied in a collapsed form. Sections of welded gabion box are linked together with stainless steel clips before despatching. Spiral rings and galvanized wire lacing is also supplied for site assembly.
Welded Gabions
Available in Galfan, or Hot Dip Galvanized to BS 729
Nominal Dimensions / Specifications
| Length x Width x Depth (metres) |
Diaphragms | Capacity (cbm) | Normal mesh (mm) x |
| 1.0 x 1.0 x 0.5 | 0 | 0.50 | 75 x 75 x 3.0 |
| 1.0 x 1.0 x 1.0 | 0 | 1.00 | 0r |
| 1.5 x 1.0 x 0.5 | 1 | 0.75 | 0r |
| 1.5 x 1.0 x 1.0 | 1 | 1.50 | 0r |
| 2.0 x 1.0 x 0.5 | 1 | 1.00 | 75 x 75 x 4.0 |
| 2.0 x 1.0 x 1.0 | 1 | 2.00 | or |
| 3.0 x 1.0 x 0.5 | 2 | 1.50 | or |
| 3.0 x 1.0 x 1.0 | 2 | 3.00 | or |
| 4.0 x 1.0 x 0.5 | 3 | 2.00 | 75 x 75 x 5.0 |
| 4.0 x 1.0 x 1.0 | 3 | 4.00 |
Plastic Coated wire Galvanized to BS 443
Nominal Dimensions / Specifications
| Length x Width x Depth (metres) |
Diaphragms | Capacity (cbm) | Normal mesh (mm) x |
| 1.0 x 1.0 x 0.5 | 0 | 0.50 | 75 x 75 x 2.70 galvanized core, plastic coated to 3.20 overall |
| 1.0 x 1.0 x 1.0 | 0 | 1.00 | |
| 1.5 x 1.0 x 0.5 | 1 | 0.75 | |
| 1.5 x 1.0 x 1.0 | 1 | 1.50 | |
| 2.0 x 1.0 x 0.5 | 1 | 1.00 | |
| 2.0 x 1.0 x 1.0 | 1 | 2.00 | |
| 3.0 x 1.0 x 0.5 | 2 | 1.50 | |
| 3.0 x 1.0 x 1.0 | 2 | 3.00 | |
| 4.0 x 1.0 x 0.5 | 3 | 2.00 | |
| 4.0 x 1.0 x 1.0 | 3 | 4.00 |
Welded Mattresses
Available in Galfan, or Hot Dip Galvanized to BS 729
Nominal Dimensions / Specifications
| Length x Width x Depth (metres) |
Diaphragms | Capacity (cbm) | Normal mesh (mm) x |
| 6 x 2 x 0.150 | 5 | 1.80 |
75 x 75 x 2.50 or 75 x 75 x 3.0 |
| 6 x 2 x 0.225 | 5 | 2.70 | |
| 6 x 2 x 0.300 | 5 | 3.60 | |
| 3 x 2 x 0.150 | 2 | 0.90 | |
| 3 x 2 x 0.225 | 2 | 1.35 | |
| 3 x 2 x 0.300 | 2 | 1.80 |
Plastic Coated Bonded on wire Galvanized to BS 443
Nominal Dimensions / Specifications
| Length x Width x Depth (metres) |
Diaphragms | Capacity (cbm) | Normal mesh (mm)xWire Diameter (mm) |
| 6 x 2 x 0.150 | 5 | 1.80 |
75 x 75 x 2.70
galvanized core,
plastic coated to 3.20 overall |
| 6 x 2 x 0.225 | 5 | 2.70 | |
| 6 x 2 x 0.300 | 5 | 3.60 | |
| 3 x 2 x 0.150 | 2 | 0.90 | |
| 3 x 2 x 0.225 | 2 | 1.35 | |
| 3 x 2 x 0.300 | 2 | 1.80 |
