Specifications
Wire diameter 0.1mm-0.55mmAperture size from 2mmx3mm to 12mmx6mm
Material stainless steel wire
pure Nickel/ Ti
PP PC PE PVC
Stainless Steel Filter for Gas or Liquid product details:
Wire diameter: 0.1mm-0.55mm (common wire 0.2mm-0.25mm), besides, use multistrand to weave.
Aperture size: from 2mmx3mm (4mmx5mm) to 12mmx6mm.
Width: 40mm 80mm 100mm 150mm 200mm 300mm 400mm 500mm 600mm etc.
Material: SUS AISI 201 202 301 302 304 304L 321 316 316L, pure Nickel, pure Ti, Monel, galvanized wire, redrawing wire, stainless steel wire and cotton thread/ plastic, PP, PC, PE, PVC, PTFE.
Surface Type: Flat type and Corrugated type
Use: mainly used for processing wire mesh demister, for the separation of liquid in the gas. Also can be extrusion forming, used in the manufacture of filter equipment.
Steam fluid strainer standard specification (Shanghai Q/SG12-1-79 and Shanghai Q/YSZZ-88-91):
Pattern |
Specification |
Standard type |
40-100 60-150 105-300 140-400 160-400 210-570 252-800 330-1050 |
Highly effective |
60-100 80-100 80-150 90-150 800-400 |
150-300 200-400 300-600 800-400 | |
High penetration |
20-100 30-150 70-400 170-560 170-600 |
Absorption of shock |
30-30 33-30 20-40 26-40 30-40 38-40 |
30-50 48-50 30-60 30-80 40-80 40-120 50-120 |
Standard steam fluid strainer technical parameter | ||||||
Filament diameter |
Net wide permission |
Stack density |
Compared to surface area |
Percentage of voids |
||
Flat silk |
Round silk |
±20 |
150 |
Flat silk |
Round silk |
0.981 |
0.1×0.4 |
0.23 |
475 |
320 |
|||
Highly effective steam fluid strainer technical parameter | ||||||
Filament diameter |
Net wide permission |
Stack density |
Compared to surface area |
Percentage of voids |
||
Flat silk |
Round silk |
±20 |
182 |
Flat silk |
Round silk |
0.977 |
0.1×0.28 |
0.19 |
626 |
484 |
|||
High penetration steam fluid strainer technical parameter | ||||||
Filament diameter |
Net wide permission |
Stack density |
Compared to surface area |
Percentage of voids |
||
Flat silk |
Round silk |
±20 |
98 |
Flat silk |
Round silk |
0.9875 |
0.1×0.4 |
0.23 |
313 |
217 |
|||
HG/T21618-1998 silk screen anti-entrainment device Monel steam fluid strainer technical parameter:
Pattern code number |
Volumetric weight kg/m3 |
Compared to surface area m2/m3 |
Percentage of voids Epsilon |
SP |
168 |
529.6 |
0.9788 |
HP |
128 |
403.5 |
0.9839 |
DP |
186 |
625.5 |
0.9765 |
HR |
134 |
291.6 |
0.9832 |
