Home > Construction & Decoration > Wire Mesh > Stainless Steel Wire Mesh > Galvanized Knitting Gas-liquid Filter Mesh

Galvanized Knitting Gas-liquid Filter Mesh

Name: Galvanized Knitting Gas-liquid Filter Mesh
Brand: Hexing
SKU: 100812167
Availability: InStock

Galvanized Knitting Gas-liquid Filter Mesh thumbnail-1

Galvanized Knitting Gas-liquid Filter Mesh photo-1

US$ 0.5 - 15 MOQ: 100 Square Meters

Key Specifications

Get Latest Price

Place of Origin:

Hebei, China

Material:

Other, stainless steel wire, galvanized wire, Nickel, Ti, Monel, redrawing

Type:

Weave Wire Mesh

Contact Supplier Request Quote Chat Now

Anping County Hexing Wire Product Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hebei, China

Material Other, stainless steel wire, galvanized wire, Nickel, Ti, Monel, redrawing

Type Weave Wire Mesh

Application Filters

Wire Diameter 0.1-0.55 mm

Technique Woven

Model Number Q/SG12-1-81

Brand Name Hexing

Specifications

Gas-liquid filter mesh
1.Wire diameter:0.1-0.55mm
2.Aperture:2x3mm (4mmx5mm)-12mmx6mm
3.Stainless steel wire
4.ISO9001

Stainless Steel Knitting Gas-liquid filter Mesh

Wire diameter: 0.1mm-0.55mm (common wire 0.2mm-0.25mm), besides, use multistrand to weave.

Aperture size: from 2mmx3mm (4mmx5mm) to 12mmx6mm.

Width: 40mm 80mm 100mm 150mm 200mm 300mm 400mm 500mm 600mm etc.

Material: SUS AISI 201 202 301 302 304 304L 321 316 316L, pure Nickel, pure Ti, Monel, galvanized wire, redrawing wire, stainless steel wire and cotton thread/ plastic, PP, PC, PE, PVC, PTFE.

Surface: Flat type and Corrugated type

Use: mainly used for processing wire mesh demister, for the separation of liquid in the gas. Also can be extrusion forming, used in the manufacture of filter equipment.

Specification (Shanghai Q/SG12-1-79 and Shanghai Q/YSZZ-88-91):

Pattern	Specification
Standard type	40-100 60-150 105-300 140-400 160-400 210-570 252-800 330-1050
Highly effective	60-100 80-100 80-150 90-150 800-400
Highly effective	150-300 200-400 300-600 800-400
High penetration	20-100 30-150 70-400 170-560 170-600
Absorption of shock	30-30 33-30 20-40 26-40 30-40 38-40
Absorption of shock	30-50 48-50 30-60 30-80 40-80 40-120 50-120

Standard steam fluid strainer technical parameter
Filament diameter dw (mm)		Net wide permission (mm)	Stack density Rho (kgm3)	Compared to surface area Alpha (m2/m3)		Percentage of voids Epsilon
Flat silk	Round silk	±20	150	Flat silk	Round silk	0.981
0.1×0.4	0.23			475	320

Highly effective steam fluid strainer technical parameter
Filament diameter dw (mm)		Net wide permission (mm)	Stack density Rho (kgm3)	Compared to surface area Alpha (m2/m3)		Percentage of voids Epsilon
Flat silk	Round silk	±20	182	Flat silk	Round silk	0.977
0.1×0.28	0.19			626	484

High penetration steam fluid strainer technical parameter
Filament diameter dw (mm)		Net wide permission (mm)	Stack density Rho (kgm3)	Compared to surface area Alpha (m2/m3)		Percentage of voids Epsilon
Flat silk	Round silk	±20	98	Flat silk	Round silk	0.9875
0.1×0.4	0.23			313	217

HG/T21618-1998 silk screen anti-entrainment device Monel steam fluid strainer technical parameter:

Pattern code number	Volumetric weight kg/m3	Compared to surface area m2/m3	Percentage of voids Epsilon
SP	168	529.6	0.9788
HP	128	403.5	0.9839
DP	186	625.5	0.9765
HR	134	291.6	0.9832
