Specifications
Expanded Metal1. Long way of mesh: 12.5-200mm
2. Short way of mesh: 5-80mm
3. Thickness: 0.5-8mm
4. Width from 600-2000mm
spray painted expanded metal
Material: Low Carbon Steel Plate, Aluminium Plate, Stainless Steel Plate, Titanium Plate, Alum-Platinum Plate, Lead Plate, Nickel Plate, etc.
Surface Treatment: PVC coated, Spray painted.
Main Processes: Punching and Pulling.
Aperture Shape: diamond, hexagonal, special shape mesh
Mesh Type: Mini-holed/ small, Standard and Heavy type mesh.
Application: used with concrete in buildings and construction, maintenance for equipments, made for arts and crafts, covering screen for first class speaker box. Also as fencing for super highway, studio, and highway. Heavy expanded metal can be used as step mesh of oil tanks, working platform, corridor and walking road for heavy model equipment, boiler, petroleum and mine well, automobile vehicles, big vessel. Also serves as reinforcing bar in construction, railway and bridges.
| Expanded Metal Specification Sheet | ||||||
Thickness |
nominal size of mesh |
Standard size |
Weight |
|||
SWD |
LWD |
Strand width |
LWM |
SWM |
||
D |
TL |
TB |
b |
B |
L |
kg/m2 |
0.5 |
3 |
6 |
|
100 |
2000 |
1.76 |
3.2 |
8 |
|||||
5 |
10 |
|||||
6 |
12.5 |
1800 |
3000 |
1.08 |
||
7 |
14 |
|||||
8 |
16 |
2000 |
3340 |
|||
9 |
20 |
|||||
12 |
30 |
1.35 |
1800 |
3600 |
0.88 |
|
10 |
25 |
1.12 |
||||
0.8 |
10 |
25 |
1.12 |
|||
12 |
30 |
1.35 |
1.41 |
|||
15 |
40 |
1.68 |
||||
1.0 |
10 |
25 |
1.12 |
|||
12 |
30 |
1.35 |
1.76 |
|||
15 |
40 |
1.68 |
||||
1.2 |
10 |
25 |
1.13 |
|||
12 |
30 |
1.35 |
2.12 |
|||
15 |
40 |
1.68 |
||||
18 |
50 |
2.03 |
||||
1.5 |
15 |
40 |
1.69 |
|
|
2.64 |
18 |
50 |
2.03 |
||||
22 |
60 |
2.47 |
||||
29 |
80 |
3.25 |
3.53 |
|||
2.0 |
18 |
50 |
2.03 |
1800 |
3600 |
|
22 |
60 |
2.47 |
||||
29 |
80 |
3.26 |
4.42 |
|||
36 |
100 |
4.05 |
||||
44 |
120 |
4.95 |
5.29 |
|||
3.0 |
36 |
100 |
4.05 |
|||
44 |
120 |
4.95 |
||||
55 |
150 |
4.99 |
2000 |
5000 |
4.27 |
|
2500 |
6400 |
|||||
65 |
180 |
4.60 |
2000 |
6400 |
3.33 |
|
2500 |
8000 |
|||||
4 |
22 |
60 |
4.5 |
1500 |
2000-3000 |
12.84 |
30 |
80 |
5 |
2000-4000 |
10.46 |
||
38 |
100 |
6 |
2000-4500 |
9.91 |
||
5 |
24 |
60 |
6 |
2000-3000 |
19.62 |
|
35 |
80 |
6 |
2000-4000 |
14.71 |
||
38 |
100 |
7 |
2000-4500 |
14.67 |
||
56 |
150 |
6 |
2000-6000 |
8.41 |
||
