Home > Products > Plug & Boot > Cat.6 UTP RJ45 Connector
Cat.6 UTP RJ45 Connector
- 1000000 Piece / Pieces per Month
- Ningbo
- T/T L/C D/P D/A Credit Card PayPal
Product Details
| Place of Origin: | Zhejiang, China | Brand Name: | SMART | Model Number: | SMT-5005M8C6 |
| Type: | RJ45 | Application: | PCB | Gender: | Male |
Product Description
Cat.6 UTP RJ45 Connector
Factory Advantages:
- OEM & ODM Services
- 25 years warranty
- 100 % Tester, 100% Pass Fluke Test
- Shortest Leading Time
Reasons To Choose US
1.Stable High Quality & Fast Delivery
2.Competitive Prices & Professional Service
3.OEM welcome
Specifcation:
Electrical
1.Current Rating:1.5 amps
2.Voltage Rating:125vac
3.Insulation Resistance:500 MΩmin
4.Contact Resistance:30 MΩmax
5.Withstanding Voltage:AC 1000V RMS 50Hz or 60Hz 1 min
Mechanical of rj45 plug :
1.Insertion Force:2.2KG.F max
2.Retention Strength:7.7KG.F min between jack and plug
3.Durability:600 mating cycles min
Material
1. PC
2.Contact Wire:Diameter 0.45mm phosphor bronze gold plating over nickel
0.35mm thickness phosphor bronze alloy selective gold plating over nickel
3.Shield:0.20~0.25mm thickness brass with tin plated
4.Gold Plating:3u inch,6u inch,15u inch,30u inch,50u inch
Environmental
Working Temperature:-40°C to 70°C
1. Q: How can I get your quotation?
A: Please provide us informations as follows:
1. Item Number & Quantity. .
2. Special Specification requirement.
3. Company Profile (Name, Tel, Fax, Address, and Webpage)
4. Any Other Relevant Details.
2. Q: How can I get a sample to check your quality?
A: After price confirmation, you can require for samples to check our quality.
3. Q: Terms of payment?
A: We accept payment as follows:
1).100% TT in advance.
2). 30% T/T deposit, 70% balance before delivery.
4. Q: Can you do OEM?
A: Yes we can.
5. Q: What about delivery time?
A: 1) Samples: within 3 days.
2) Goods: 15-20days usually.
6. Q: Factory Inspection?
A: Any time .
7. Welcome to our factory for inspection.
