HD SDI Cctv Camera VandalProof 4-9mm Lens 21pcs IR-LED EST-SDI7033

Name: HD SDI Cctv Camera VandalProof 4-9mm Lens 21pcs IR-LED EST-SDI7033
Brand: ESTER
SKU: 100790399

US$ 100 - 120 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ESTER

Model Number:

EST-SDI7033

Shenzhen Enster Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ESTER

Model Number EST-SDI7033

Type Analog Camera

Style Dome Camera

Sensor CMOS

Technology Infrared

Special Features Waterproof / Weatherproof

HD CCTV,2M Active Pixels,
HD-SDI Output1080P
WDR,DNR, Digital Zoom,
Privacy Mask, Motion Detection

Progressive scan
External adjust for Zoom&Focus

1/3" CMOS Digital: 1080(30P), 720(60P) Max: 1;
1100TV lines(1082P)
Varifocal 4-9mmLens (2M Pixels)
21 pieces IR-LED

Model	EST-SDI7033
Camera Type	Color Weatherproof IR Camera
Image Sensor	1/ 2.7” Panasonic CMOS
Total Pixels	2010(H) x 1108(V) = 2,227,080
Effective Pixels	1944(H) x 1092(V)= 2,122,848
Scanning system	Progressive
Resolution	Digital: 1080(30P), 720(60P) Max: 1,100TV lines(1080P)
Min. Illumination	Color : 1.0 lux, BW : 0.5 lux,
Min. Illumination	Color DSS : 0.002 lux, BW DSS : 0.0008 lux
Video Output	Digital : BT.1120, HD-SDI, Analog : NTSC/PAL CVBS(w/o WDR)
S/N Ratio	More than 50dB (AGC off)
Function
Lens	DC/Manual
AGC	0 – 20 steps
Shutter Speed	AUTO/MANUAL(1/50(60) ~ 1/60,000 sec)
Digital Slow Shutter	Off/On(x4)
Brightness	0 - 20
WDR/BLC	Off/BLC/WDR
ACE	Off/On
Day&Night	Auto/Color/B&W
White Balance	Auto/Auto ext/Pushing/Manual
DNR (Digital Noise Reduction)	Off/Low/Middle/High
Mirror	Off/On
Flip	Off/On
Sharpness	0 – 10 steps
Shading	Off/On
Digital Zoom	0 – 96 steps
Privacy Mask	32 Masks
Motion Detection	Off/On
Language	Korean/Chinese/English
Camera
Lens Mount	Varifocal Lens 4-9mm
Infrared Luminary	21pcs
Illuminate distance	30m
Infrared Wavelength	850 nm
Waterproof Criterion	IP 66
I/O Connector	HD-SDI: SMA connector, CVBS: BNC connector
Supplied Voltage	DC12V Voltage
Power Consumption	IR On: 400mA max., IR Off: Less than 130mA
