Specifications
Corn flakes machine1. twin screw extruder
2. Flakes, cereals, snacks
3. Corn flour as raw materials
Corn flakes machines, breakfast cereal machine
1. Description: Corn flakes are a popular breakfast cereal manufactured by twin-screw extruder or single screw extruder through the treatment of flakes of grain, served with milk and marshmallows, were a very popular food among the families.
2. Raw materials: adopts corn flour as raw materials
3. Products: This line can be used to produce corn flakes, breakfast cereals, snacks by adjusting the moulds from extruder
4. Capacity: 150kg/h, 300kg/h
5. Flow chart:
Mixing system---Extrusion system----Cooling system—Flaking system--Drying system—Toasted system---Sugar Spraying system ---Drying system---- Packing system
6. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers' Local voltage according to different countries
7. Machines Materials: All the machines are made by stainless steel
8. Technical Parameters
Model |
Installed power |
Real power |
Output |
Dimension |
AMC65 |
140kw |
90kw |
150kg/h |
39000x1200x2200mm |
AMC70 |
160kw |
120kw |
200kg/h |
41000x1500x2200mm |
AMC85 |
190kw |
140kw |
300kg/h |
43000x3500x4300mm |
9. Samples Pictures
