Home > Security & Protection > Surveillance, Control & Protection > CCTV Camera > Enster Full HD 2MP HD-SDI 1080P Output WDR SDI Camera With Varifocal 2.8-12mm Quality Choice
Enster Full HD 2MP HD-SDI 1080P Output WDR SDI Camera With Varifocal 2.8-12mm Quality Choice
US$ 10 - 30
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Enster
Model Number:
EST-W7561-SDI
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Full AHD CCTV 1080p MINI Hidden Camera New Products Digital Security IP CameraUS$ 22 - 25MOQ: 1 Piece -
IR Camera CCTV Camera System HDMI H.264 CCTV DVR Kit 4 CH Home Security Camera System 16 Channel Cctv Dvr KitsUS$ 73 - 75MOQ: 1 Piece
-
IR Camera CCTV Camera System HDMI H.264 CCTV DVR Kit 4 CH Home Security Camera System 4ch Cctv Dvr KitUS$ 73 - 75MOQ: 1 Piece
-
IR Camera CCTV Camera System HDMI H.264 CCTV DVR Kit 4 CH Home Security Camera System H.264 Diy Dvr KitUS$ 73 - 75MOQ: 1 Piece
-
IR Camera CCTV Camera System HDMI H.264 CCTV DVR Kit 4 CH Home Security Camera System Cctv Dvr KitUS$ 73 - 75MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Enster
Model Number
EST-W7561-SDI
Type
Analog Camera
Style
Bullet Camera
Sensor
CCD
Technology
Infrared
Special Features
Waterproof / Weatherproof
Main Feature:
* HD SDI surveillance CAMERA
* 2M ACTIVE PIXELS digital camera
* WDR,DNR, Digital Zoom
* Privacy Mask, Motion Detection
* OUTPUT 1080
Specification:
| Model No. | EST-W7561-SDI | EST-W7565-SDI | EST-W7563-SDI |
| Camera Type | Color Weatherproof IR Camera | Color Weatherproof IR Camera | Color Weatherproof IR Camera |
| Image Sensor | 1/ 2.7” Panasonic CMOS | 1/ 2.7” Panasonic CMOS | 1/ 2.7” Panasonic CMOS |
| Total Pixels | 2010(H) x 1108(V) = 2,227,080 | 2010(H) x 1108(V) = 2,227,080 | 2010(H) x 1108(V) = 2,227,080 |
| Effective Pixels | 1944(H) x 1092(V)= 2,122,848 | 1944(H) x 1092(V)= 2,122,848 | 1944(H) x 1092(V)= 2,122,848 |
| Scanning system | Progressive | Progressive | Progressive |
| Resolution | Digital: 1080(30P), 720(60P) Max: 1,100TV lines(1080P) | Digital: 1080(30P), 720(60P) Max: 1,100TV lines(1080P) | Digital: 1080(30P), 720(60P) Max: 1,100TV lines(1080P) |
| Min. Illumination | Color : 1.0 lux, BW : 0.5 lux, | Color : 1.0 lux, BW : 0.5 lux, | Color : 1.0 lux, BW : 0.5 lux, |
| Color DSS : 0.002 lux, BW DSS : 0.0008 lux | Color DSS : 0.002 lux, BW DSS : 0.0008 lux | Color DSS : 0.002 lux, BW DSS : 0.0008 lux | |
| Video Output | Digital : BT.1120, HD-SDI, Analog : NTSC/PAL CVBS(w/o WDR) | Digital : BT.1120, HD-SDI, Analog : NTSC/PAL CVBS(w/o WDR) | Digital : BT.1120, HD-SDI, Analog : NTSC/PAL CVBS(w/o WDR) |
| S/N Ratio | More than 50dB (AGC off) | More than 50dB (AGC off) | More than 50dB (AGC off) |
| Function | |||
| Lens | DC/Manual | DC/Manual | DC/Manual |
| AGC | 0 – 20 steps | 0 – 20 steps | 0 – 20 steps |
| Shutter Speed | AUTO/MANUAL(1/50(60) ~ 1/60,000 sec) | AUTO/MANUAL(1/50(60) ~ 1/60,000 sec) | AUTO/MANUAL(1/50(60) ~ 1/60,000 sec) |
| Digital Slow Shutter | Off/On(x4) | Off/On(x4) | Off/On(x4) |
| Brightness | 0 - 20 | 0 - 20 | 0 - 20 |
| WDR/BLC | Off/BLC/WDR | Off/BLC/WDR | Off/BLC/WDR |
| ACE | Off/On | Off/On | Off/On |
| Day&Night | Auto/Color/B&W | Auto/Color/B&W | Auto/Color/B&W |
| White Balance | Auto/Auto ext/Pushing/Manual | Auto/Auto ext/Pushing/Manual | Auto/Auto ext/Pushing/Manual |
| DNR (Digital Noise Reduction) | Off/Low/Middle/High | Off/Low/Middle/High | Off/Low/Middle/High |
| Mirror | Off/On | Off/On | Off/On |
| Flip | Off/On | Off/On | Off/On |
| Sharpness | 0 – 10 steps | 0 – 10 steps | 0 – 10 steps |
| Shading | Off/On | Off/On | Off/On |
| Digital Zoom | 0 – 96 steps | 0 – 96 steps | 0 – 96 steps |
| Privacy Mask | 32 Masks | 32 Masks | 32 Masks |
| Motion Detection | Off/On | Off/On | Off/On |
| Language | Korean/Chinese/English | Korean/Chinese/English | Korean/Chinese/English |
| Camera | |||
| Lens Mount | Varifocal Lens 2.8 -12mm | Varifocal Lens 2.8 -12mm | Varifocal Lens 2.8 -12mm |
| Infrared Luminary | 60 pieces IR-LED | 2 PCS Array of infrared light | 42 pieces IR-LED |
| Infrared Wavelength | 850 nm | 850 nm | 850 nm |
| Illuminate Distance | More than 50 M | More than 40 M | More than 40 M |
| Waterproof Criterion | IP 66 | IP 66 | IP 66 |
| I/O Connector | HD-SDI: SMA connector, CVBS: BNC connector | HD-SDI: SMA connector, CVBS: BNC connector | HD-SDI: SMA connector, CVBS: BNC connector |
| Supplied Voltage | DC12V Voltage | DC12V Voltage | DC12V Voltage |
| Power Consumption | IR On: 400mA max., IR Off: Less than 130mA | IR On: 400mA max., IR Off: Less than 130mA | IR On: 400mA max., IR Off: Less than 130mA |
| Dimensions | 80x 90 x160mm | 80x 90 x160mm | 80x 90 x160mm |
| Weight | Approx. 1.3kg | Approx. 1.3kg | Approx. 1.3kg |
Certification:
Company Show:
Business around the World:
Application to any need place:
Basic Connection System:
r service
Satisfied Service:
1.Any inquiries will be replied within 24 hours
2.Professional manufacturer. Welcome to visit our website: www.enster.com
3.OEM/ODM available:
1).Silk print logo on the camera;
2). Customized camera housing;
3).Customized Color box
4).Any your idea on camera we can help you to design and put it into production
4.High quality, fashion designs ,reasonable & competitive price, fast lead time .
5.After-Sale Service:
1). All products will have been strictly Quality Checked in house before packing
2). All products will be well packed before shipping.
3).All our products have 2 year warranty,And we sure the product will be free from maintenance within warranty period.
6.Faster delivery:
Sample order in stock ,and 3--7days for bulk production
7.Payment:
You can pay for the order via :T/T,Western Union ,Paypal & MoneyGram .
8.Shipping
We have strong cooperation with DHL, TNT, UPS, FEDEX, EMS , China Air Post.
You also can choose your own shipping forwarder.
