Home > Metallurgy, Mineral & Energy > Magnetic Material > NdFeB Magnet > Magnetic Powder for Magnetic Damping Plate

Magnetic Powder for Magnetic Damping Plate

Name: Magnetic Powder for Magnetic Damping Plate
Brand: Bgrimm
SKU: 100778995

Magnetic Powder for Magnetic Damping Plate thumbnail-1

Magnetic Powder for Magnetic Damping Plate thumbnail-2

Magnetic Powder for Magnetic Damping Plate photo-1

Magnetic Powder for Magnetic Damping Plate photo-2

Negotiable MOQ: 100 Kilograms (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Beijing, China

Brand Name:

Bgrimm

Model Number:

BMXF-2D

Contact Supplier Request Quote Chat Now

Bgrimm Magnetic Materials & Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Beijing, China

Brand Name Bgrimm

Model Number BMXF-2D

Type Permanent

Composite Ferrite Magnet

Shape Other, powder

Application Industrial Magnet

1. Introduction of Product

BMXF-2H is a barium ferrite powder for the preparation of semi-anisotopic bonded magnets. It is compatible with the matrix material, such as CPE, NBR. Permanent magnets are formed by extrudering technique.

2. Typical Powder Properties

Chemical Composition BaFe₁₂O₁₉

Average Partical Size 1.4-2.0 µm

Moisture <0.5 %

Property of powder compacted model (Test condition A)

Br(Gs)	bHc(Oe)	iHc(Oe)	(BH)max(MGOe)
1400-1500		2130-2390	0.39-0.49

3. Bonded Magnet properties(Test Condition B)

Property	Units	Values
Weight% Loading	%	89.5
Residual Induction(Br)	Gs	2100-2300
Coercive Force(bHc)	Oe	1500-1900
Intrinsic Coercive Force(iHc)	Oe	1940-2340
Peak Energy Product(BHmax)	MGOe	1.0-1.3

4. Test condition

Test condition A:

40 grams of powder mixed with 4 grams of wax heated at 110°C for 15 minutes to make the wax melt. Then make the mixed powder pass through a 40-mesh sifter. 18 grams of the - 40-mesh powder is compressed at a 1.6´10⁴N/cm²pressure to get a green sample for magnetic properties measuring.

Test condition B:

Compounding Equipment: Two roll rubber mill.

The two rollmill is heated to 80 °C . 32 grams of binder is sheeted onto the mill and 460 grams of BMXF-2H powder is added and mixed with the binder. This mill sheet is calendered onto another which roll gap is adjusted to produce a 2.7mm sheet. A portion of this mill sheet is evaluated to determine magnetic properties.

5. Inspection Record for User

1) Name of material

2) Lot No.

3) Delivered Weight

4) Moisture

5) Magnetic Properties (under test condition)

For more information,please contact:

BGRIMM MAGNETIC MATERIALS & TECHNOLOGY CO.,LTD.

6-5Building,ABP,No 188 Western Road, South 4th Ring Road, Beijing China 100070

Phone:86-10-63703380-206 Fax: 86-010-67586512
