Help CenterDOPPLER Curved Phased Array Transducer
Related Products
-
Dual Crystal Transducer and ProbeUS$ 112 - 152MOQ: 1 Piece -
TOFD Transducer WedgeUS$ 50 - 150MOQ: 1 Piece
-
ACCUR-5 Ultrasonic Thickness Measurement InstrumentNegotiableMOQ: 1 Piece
-
Dopler TOFD Transducers and ProbesUS$ 240 - 300MOQ: 1 Piece
-
Immersion Waterproof ProbeUS$ 140 - 189MOQ: 1 Piece
Specifications
1.Electronic beam steering/angulation2.Electronic focal length adjustments
3.EN12688-2 approved
Overview
Doppler’s ultrasonic probe production line includes normal probes, narrow-pulse normal probes, angle probes, variable-angle probes, dual normal probes, immersion probes and phased-array probes, etc. Besides, OEM orders are acceptable according to probe specification and quantity. Doppler’s probes can meet your demands for perfection
Key Feature
1.Electronic controls beam angle,focusing and scanning step size
2.Less setting and scanning
3.Electronic focusing-Increased sentivities & Singal-to-noise ratios
4.Redution of Exemption of mechanical of manual controls
5.Wedges may replaceable when Immersion method applied.
Key benefits
1.Probes are designed to have a low-profile probe/wedge combination for easier access in restricted areas.
2.Wave layers with acoustic adaptation to Rexolite
3.Captive anchoring screws are provided with the probe.
4.A wide selection of wedges is available to suit any angle beam
5.Reduced manual manipulation.
6.Reduced scanning surface contact area necessary (footprint).
7.Reduced need for multiple inspections with specifically angled or focused probes.
8.Increased inspection speed and efficiency.
9.Increased coverage of inspection area.
Application
1:Power system: pressure vessels,Pipelines
2:Aviation / Aerospace: Welding,composites delamination & abhesion , landing gears inspection
3:Transportation:composites delamination & abhesion,planks
4:Conventional: Larg area scanning,planks,sticks,pipelines thickness measurement.
Picture of Matrix 2D/1.5Dphased array probes(transducers)
1-3 piezo composite material
Suitcase for probes
Quality Certificate
Ordering Instructions
Conventional Ultrasonic Phased Array transducer frequency is 1MHz~15MHz.Element quantity is from1 to 128,custom order can be up to 1024 elements.Our company can provide all kinds of array types of transducer including Linear(L),Matrix(M),Annular(A),Concave(C),Wedge Integrated and so on.Other type of transducer can be customize according to custom's requirement.Wedge,connectors,connector switchs and extension cables also can be customized.
