Help CenterMCLED MF04-40W Bridgelux ATEX LED Explosion Proof Light Hazardous Area Led Lighting
Related Products
-
LED COB Bridgelux IP67 ATEX MF01-50W-100W Hazardous Area Lighting LED Explosion Proof LightUS$ 120 - 152MOQ: 1 Piece -
MCLED Aluminum IATEX MF-TH-80W Bridgelux IP 67 LED Gas Station Explosion Proof LightUS$ 130 - 175MOQ: 1 Piece
-
100W MCLED Aluminum ATEX MF-C-100WD High Luminance Bridgelux IP 67 LED Explosion Proof Light T6US$ 130 - 175MOQ: 1 Piece
-
MCLED MF01-140W Bridgelux IP67explosion-proof Led Torch Light LED Explosion Proof Light ATEXUS$ 160 - 170MOQ: 1 Piece
-
MCLED COB MF04-20W Bridgelux LED Explosion Proof Light ATEX IP67US$ 1 - 100MOQ: 1 Set
|
Model Item |
MF04-20-40W |
|
LED Consumption |
130W,140W,150W |
|
System Consumption |
Power*1.1 |
|
Input Voltage |
85-265V |
|
Working Power Frequency Range |
50Hz/60Hz |
|
Power Factor |
>0.95 |
|
Total Harmonic Distortion |
<20% |
|
Working Environment |
working temperature: -25℃-45℃ Woking Humidity:0-100% |
|
Average Temperature in 24 hrs |
<35° |
|
Surface Highest Temperature |
<60° |
|
Junction Temperature(TJ) |
<70° |
|
Lamp Luminous Efficacy(Lm/W) |
>110lm/w |
|
LED Initial Flux (Lm) |
LED consumption*110lm/w |
|
Lamp Efficiency(%) |
>90% |
|
Color Temperature |
2700-7000K |
|
Color Rendering Index(CRI) |
>70 |
|
LED Life Span |
>50000 |
|
Protection Grade |
IP67 |
|
Lens Light Transmittance |
>90% |
|
Beam Angle |
60-120° |
|
Net weight |
3.8 kgs |
|
Gross weight |
4.5kgs |
|
Packing size |
42*42*30cm |
|
|
Note:Lens can be changed according to client's specific requirement. |
||
Q2. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
A: Amercial bridgelux
Q4: Can we have the sample for testing?
A: Of course the samples are possible. But we will charge for it. However, if the quantity is more than 250pcs, we will return the sample charge to you.
Q5: How long we can get the sample.
A: The lead time for samples ia usually 3 days.
