Home > Manufacturing & Processing Machinery > Cutting & Fold-bend Machine > Bending Machine > W24S-100 Tube Rolling Machine
US$ 15,000 - 30,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
haiwei
Payment & Shipping
Payment Methods:
Port of Shipment:
any port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Flat Bar Rolling Machine,fabric Rolling Machine,tube Bending Machine,square Tube Bending MachineUS$ 80,000 - 90,000MOQ: 1 Set -
Metal Rolling MachineUS$ 80,000 - 90,000MOQ: 1 Set
-
W24s Series Flat Bar Rolling MachineUS$ 12,500 - 90,000MOQ: 1 Set
-
W24S-45 Profile Rolling MachineUS$ 20,000 - 30,000MOQ: 1 Set
-
Tube Bending MachineUS$ 40,000 - 60,000MOQ: 1 Set
Condition
New
Place of Origin
Jiangsu, China
Brand Name
haiwei
Model Number
W24s-16
Machine Type
Roll Forming Machine
Raw Material
Pipe
Material / Metal Processed
Carbon Steel
Power
Hydraulic
Automation
Automatic
Extra Services
End Forming
Certification
ISO 9001:2000
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1.channel steel2. joist steel
3.flat steel
4.square steel and round steel etc
| Technical parameters | W24S | |||||
| 6 | 16 | 30 | 45 | 75 | 100 | |
| Flexural modulus of the largest cross-section profiles | 6 | 16 | 30 | 45 | 75 | 100 |
| Coiling speed(m/min) | 6 | 5 | ||||
| Yielding Limit of Sheet Metal(mpa) | S=250 | |||||
| Maximum cross section(mm) | 40×5 | 70×8 | 80×8 | 90×10 | 100×10 | 120×12 |
| Minimum bending diameter(mm) | 800 | 1000 | 1200 | 1500 | 2000 | 2500 |
| Minimum cross section(mm) | 20×3 | 30×3 | 35×3 | 36×5 | 38×4 | 40×5 |
| Minimum bending diameter(mm) | 400 | 550 | 560 | 600 | 600 | 720 |
| Maximum cross section(mm) | 50×5 | 80×8 | 90×10 | 100×10 | 120×12 | 140×16 |
| Minimum bending diameter(mm) | 800 | 1000 | 1100 | 1300 | 1600 | 1800 |
| Minimum cross section(mm) | 20×3 | 30×3 | 35×3 | 36×5 | 38×4 | 45×5 |
| Minimum bending diameter(mm) | 400 | 550 | 500 | 600 | 700 | 760 |
| Channel model | 8 | 12 | 16 | 20 | 25 | 28 |
| Minimum bending diameter(mm) | 600 | 800 | 800 | 1000 | 1100 | 1700 |
| Channel model | 8 | 12 | 16 | 20 | 25 | 28 |
| Minimum bending diameter(mm) | 700 | 900 | 1000 | 1150 | 1600 | 1700 |
| Maximum cross section(mm) | 100×18 | 150×25 | 180×25 | 200×30 | 220×40 | 250×40 |
| Minimum bending diameter(mm) | 600 | 700 | 800 | 900 | 1000 | 1200 |
| Maximum cross section(mm) | 50×12 | 75×16 | 90×20 | 100×25 | 110×40 | 120×40 |
| Minimum bending diameter(mm) | 500 | 760 | 800 | 1000 | 1100 | 1300 |
| Maximum cross section(mm) | 42×4 | 76×4.5 | 89×5 | 89×8 | 114×5 | 159×5 |
| Minimum bending diameter(mm) | 500 | 750 | 900 | 900 | 1200 | 2000 |
| Maximum cross section(mm) | 38 | 52 | 62 | 75 | 85 | 90 |
| Minimum bending diameter(mm) | 450 | 600 | 600 | 800 | 1000 | 1100 |
| Maximum cross section(mm) | 45×3 | 60×4 | 70×4 | 80×6 | 90×8 | 100×10 |
| Minimum bending diameter(mm) | 750 | 900 | 1000 | 1200 | 1600 | 2000 |
This machine can be expected to complete the pre-bending, roll round and round school process. The two machines under the main drive roller, can also work in three main drive roller roller, the roller position is fixed, the two side rollers rotating arc movement around a fixed center movements, hydraulic control, displacement of liquid crystal display, showing accuracy of 0.1mm. It is conducive to forming process control; both sides of the device has a roller, which will help to ensure that non-symmetrical cross-section happen. advanced technology, feature-wide, also can put horizontally and vertically.
Three work roll are major pinch roll, two side roll can make arc vertical movement around fixed center of gyration, There are roll-lift device on the both sides of work roll which can assure the quality of asymmetry section bending profile. This machine is advanced profile equipment currently at home and abroad with advance structure and reliable operation. Advance structural general or special mold can be configured by the machine, this machine is with convenient operation, high efficiency and great popularity.
Half hydraulic and hydraulic bending machine are famous for its good quality and advanced technology. It is convenient to use
Profile bending machine is a new kind of bending equipment which is introduced from Italy
technology by our company, by changing different mold, this machine can bend various kind of
steel profile such as angel steel, channel steel, joist steel, flat steel, square steel and round steel.
This machine can complete circle-rolling and circle-checking procedures at one time which are widely used in oil industry, chemical industry,
hydropower, shipbuilding industry and machinery manufacture industry.
