Waterproof IP65 Aluminum Lighting Fixture
US$ 13 - 25
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Light Source:
Fluorescent
Input Voltage(V):
110-240V
Lamp Power(W):
116
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Ningbo Guangzhou Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
100W 150W 250W Tunnel Light FixtureUS$ 20 - 37MOQ: 50 Pieces -
Tunnel Wall LightUS$ 28 - 65MOQ: 50 Pieces
-
60 Watt Led Tunnel Light 1200mm Aluminum Light Fixture With t8 Led Tunnel LampUS$ 28 - 65MOQ: 50 Pieces
-
Tunnel Lighting Ip65US$ 28 - 65MOQ: 10 Pieces
-
50w Led Tunnel Lighting 4ft 1200mm Aluminum Light Fixture With t8 Led Tunnel LampUS$ 28 - 65MOQ: 1 Piece
Light Source
Fluorescent
Input Voltage(V)
110-240V
Lamp Power(W)
116
Lamp Luminous Flux(lm)
10000
Lamp Luminous Efficiency(lm/w)
85
Color Temperature(CCT)
Cool White
Working Temperature(℃)
-40, 50
Working Lifetime(Hour)
15000
Lamp Body Material
Aluminum
IP Rating
IP65
Certification
CCC, CE, CQC, GS
Base Type
G13
Place of Origin
Jiangsu, China
Brand Name
SREGM Waterproof IP65 aluminum lighting fixture
Model Number
YZ/SDD Waterproof IP65 aluminum lighting fixture
Specifications
Waterproof IP65 aluminum lighting fixtureInsulation class: I
Impact resistance: IK10
Waterproof IP65 aluminum lighting fixture
Applicaton
- Highway tunnel
- subway
- city railway
- underground parking
- and other places of lighting required.
Features
- Tunnel luminaire for surface-mounting, suspended mounting or fixing to tunnel substructure
- Highly specular reflector, direct symmetrical distribution
- Aluminum housing with mounting straps and cover catches of stainless steel sealing on one level
- Frameless cover of toughened safety glass
Specification
| Description | |
| Housing | Aluminum Alloy |
| Diffuser | 5mm toughened glass |
| Clips | Stainless steel |
| Specular reflector | vacuum coating |
| Rated Voltage | 100-240V AC |
| IP rating | IP65 |
| Socket | G13, PC |
| Gasket | Natural silicon |
| Cable gland | D10mm, copper |
| Bracket | Stainless steel |
| Accessary | 4 screws, 4 bushings and 4 washers |
| Insulation class | I |
| Mounting: | Ceiling surface or wall mounted |
Photoes
Dimentions:
| T8 Fluorescent light | ||||||
| Item No. | Power | Lumen (lm) | No. of clips | Demension (mm) | Packing size (mm) | pcs/ctn |
| YZ8118E | 1X18W | 1400 | 4 | 670x90x90 | 740x305x210 | 6 |
| YZ8218E | 2X18W | 2800 | 4 | 670x125x90 | 740x290x210 | 4 |
| YZ8136E | 1X36W | 2800 | 8 | 1270x90x90 | 1340x305x210 | 6 |
| YZ8236E | 2X36W | 5600 | 8 | 1270x125x90 | 1340x290x210 | 4 |
| YZ8158E | 1X58W | 4600 | 10 | 1570x90x90 | 1640x305x210 | 6 |
| YZ8258E | 2X58W | 9200 | 10 | 1570x125x90 | 1640x290x210 | 4 |
| T5 Fluorescent light | ||||||
| Item No. | Power | Lumen (lm) | No. of clips | Demension (mm) | Packing size (mm) | pcs/ctn |
| YZ5114E | 1X14W | 1000 | 4 | 630x90x90 | 740x305x210 | 6 |
| YZ5214E | 2X14W | 2000 | 4 | 630x125x90 | 740x290x210 | 4 |
| YZ5128E | 1X28W | 2300 | 8 | 1220x90x90 | 1340x305x210 | 6 |
| YZ5228E | 2X28W | 4500 | 8 | 1230x125x90 | 1340x290x210 | 4 |
| YZ5135E | 1X35W | 2800 | 10 | 1520x90x90 | 1640x305x210 | 6 |
| YZ5235E | 2X35W | 5600 | 10 | 1520x125x90 | 1640x290x210 | 4 |
