press brake for sale WC67Y-125/3200

FOB Price

USD $11,500 - $20,000 / Piece

1 Piece(Min.Order)

Supply Ability 80 Piece / Pieces per Month
Port shanghai
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Jiangsu, China
Brand Name	haiwei	Model Number	WC67Y-100/3200
Machine Type	Press Brake	Raw Material	Sheet / Plate Rolling
Material / Metal Processed	Stainless Steel	Power	Hydraulic
Automation	Automatic	Extra Services	End Forming
Certification	ISO 9001:2000	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

1,cnc control
2,protective backgauge
3,ball screw

Feature and Advantages:

(1). This machine adopts hydraulic electric control, sliding block stroke can be adjusted, and have some fixed, semi-automatic, automatic movements such as norm, using dynamic specification can easily test and adjustment

(2). lift bending machine design, double oil cylinder work at the same time, balance, convenient operation, safety

(3). The dead point have confirmed when rolling function, ensure that the workpiece precision

(4). Under the condition of the relevant national standards, bending Angle precision of plus or minus 45 '. (refer to standard JB/T22572-1999)

(5). A slow decline control function, the operator can better control the workpiece

No	Name		Data	Unit	Remarks
1	Nominal pressure		1000	KN
2	Length of working table		3200	mm
3	Plate strength		≤450	N/mm²
4	The distance of column		2600	mm
5	Ram stroke		150	mm
6	Max opening height		450	mm
7	Depth of throat		320	mm
8	Ram speed	Free	60	mm
		Running	7	mm
		Return back	70	mm
9	Main	Type	Y160M-6 B5
		Power	7.5	KW
		Speed	970	rpm
10	Max pressure of system		26	Mpa
11	Axial pump	Type	25MCY14-1B
		Speed	25	L/min
		Pressure	31.5	Mpa
12	Out size	Length	3600	mm
		Width	1500	mm
		Height	2600	mm
13	Weight		6800	kg

Usage

The hydraulic press brake can be applied to boiler tank, air conditioning channels, sheet metal cover, cone making and other aluminum and steel fabrication, marine and ship building, pressure vassals and wind mills.
