mechanical shearing machine
- 120 Piece / Pieces per Month
- any port of china
- T/T L/C D/P D/A Credit Card PayPal
- Omax Maxiem Pump Minor Maint 302700 Retainer Man 301873 301353 Ring Seal 303274 Major Maintenance Kit
- Dual Port Swivels Seal Replacement Kit 308616 Package for Omax 308620-1 2 3
- 60KPSI SL-IV SL-V WK000216 05007786 Bushing Retainer Flange for KMT Water Jet Cutting
- Waterjet Spare Parts 90K WK000190 189 20468617 20475871 Pneumatic Dump Valve
- 1-14493 UHP 90 degree 1/4 in. 94k Waterjet Repair Kit 015093-1 Swivel Rebuild Kit for Water Jet Cutt
- Hydraulic Waste Car Body Shell Gantry Shear Machine for Scrap Recycling Center
Product Details
Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | haiwei |
Model Number: | Q11-6*2500 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
mechanical shearing machinefoot pandel operated
high speed and precision
long working life
main technical data
Name | Data | Unit | Remarks | |
Max cutting thickness | 6 | mm |
| |
Max cutting width | 2500 | mm |
| |
Depth of throat | 210 | mm |
| |
Cutting angle | 1°45’ |
|
| |
Intensity of sheared material | 450 | N/m |
| |
Distance of back gauge | 20-500 | mm |
| |
Times of stroke | 40 | Times/min |
| |
Cutting times | 15 | Times/Min |
| |
Blade length | 2540 | mm |
| |
Height of working table | 650 | mm |
| |
Speed of wheel | 302 | Circle/min |
| |
Main motor | Type | Y132M-4 |
| B5 |
Power | 7.5 | KW |
| |
Speed | 960 | rpm |
| |
Size | 3800*1800*1600 | mm |
| |
Weight | 4500 | Kg |
|
1,main construction :
steel-welded construction, vibration to eliminate stress with high strength and good rigidity
2,main parts :
A, main electrical parts supply by Siemens
D, main motor: China
E, blade: China material 9CrSi
3,inspect standard: National standard : GB/T 14349-93
