Help CenterChina Nantong Teli QC12Y-8*3200 Hydraulic Swing Beam Shearing Machine
Related Products
-
QC11Y Seires 3200mm Shearing MachineUS$ 15,500 - 20,000MOQ: 1 Piece -
QC11Y Seires Precision Shearing MachineUS$ 15,500 - 20,000MOQ: 1 Piece
-
QC11Y Seires Plates Hydraulic Guillotine Shearing MachineUS$ 15,500 - 20,000MOQ: 1 Piece
-
QC11Y Seires Metal Sheet Guillotine Shearing MachineUS$ 15,500 - 20,000MOQ: 1 Piece
-
QC11Y Seires nc Hydraulic Guillotine Shear MachineUS$ 15,500 - 20,000MOQ: 1 Piece
Specifications
hydraulic swing beam shearing machine1,E10 nunber display system
2,9CrSi blade four cutting edges
3,ball screw backgauge
hydraulic swing beam shearing machine
QC12K-8×3200
hydraulic swing shearing machine
performance and price
1,working setting :
Power: 380V (AC)±10% 50HZ±1HZ 3PH
Temperature: -10°C - 45°C
humidity ≤95%
working condition: can work 24 hours continuously
2,main technical data:
Name |
Data |
Unit |
Remarks |
||||||
Max cutting thickness |
8 |
mm |
|
||||||
Max cutting width |
3200 |
mm |
|
||||||
Intensity of the sheared material |
500 |
N/mm2 |
|
||||||
Shearing angle |
1°30′ |
|
|||||||
Max stroke of backgauge |
20-600 |
|
|||||||
Times of stroke |
14 |
Per/min |
|
||||||
Distance between vertical columns |
3590 |
mm |
|
||||||
The length of blade |
3300 |
mm |
|
||||||
Height of the work bench |
800 |
mm |
|
||||||
Thickness of bench support plate |
40 |
mm |
|
||||||
Main motor |
Model |
Y132M-4 |
China |
||||||
Power |
7.5 |
KW |
|||||||
Speed |
1450 |
rpm |
|||||||
Backgauge motor |
Model |
Y802-6 |
B5 |
||||||
Power |
0.55 |
KW |
|
||||||
Speed |
900 |
rpm |
|
||||||
Axial piston Pump |
Model |
25MCY14-1B |
China |
||||||
Power |
25 |
L/min |
|||||||
Pressure |
31.5 |
MPa |
|||||||
Dimensions |
Length |
3850 |
mm |
|
|||||
Width |
1700 |
|
|||||||
Height |
1800 |
|
|||||||
Weight |
7500 |
KG |
|
||||||
Machine price |
12000 |
USD |
FOB shanghai |
||||||
3,main performance :
3-1,steel-welded construction, vibration to eliminate stress with high strength and good rigidity
3-2,adopted ATOS valves from Italy.
3-3,fitted with manual operation ,semi-automatically operation , full-automatically operation three working mode.
3-4,blade clearance adjusted by number marked plate ,quickly ,accurate ,convenient
3-5,the edge of upper knife carrier is forming into a curved surface to ensure the clearance identity between upper and lower blades during the shearing process.
3-6,the upper carrier derived by right and left oil cylinders and with the support of fulcrum eccentric sleeve to fulfill shearing function.
3-7,it has also equipped with light to overlapping the draw line on the plate .
3-8,main electrical parts adopted Siemens.
3-9,hydraulic system oil sealing import from Japan NOK.
3-10, DA360 CNC system and ball screw for backgauge.
