Help CenterW24S-75 Manual Pipe Bender Machine
Related Products
-
Rolling Pipe Bending Machine W24s-100US$ 30,000 - 40,000MOQ: 1 Set -
Steel Pipe Rolling Machine W24s-100US$ 30,000 - 40,000MOQ: 1 Set
-
Pipe Bending Machine CostUS$ 30,000 - 50,000MOQ: 1 Set
-
Large Diameter Pipe Bending MachineUS$ 30,000 - 50,000MOQ: 1 Set
-
Hand Operated Pipe Bending MachineUS$ 30,000 - 50,000MOQ: 1 Set
pipe bending machine used
| Place of Origin: | Jiangsu China (Mainland) | Brand Name: | Haiwei | Model Number: | W24s |
| Machine Type: | Section bendng machine | Raw Material: | Sections /Rolling | Material / Metal Processed: | Carbon Steel/S.S/M.s |
| Power: | Hydraulic | Automation: | Automatic | Certification: | ISO 9001:2000.SGS.BV |
| Extra Services: | End Forming | Exported to Countries: | Russia,Agentina,india and soon | Color: | on request |
| Control system: | CNC/NC/PLC | Electric: | SIEMENS | Bearing: | NOK |
| USE1: | pre-bending | USE2: | arc-rolling | USE3: | record process |
| PLC: | Ormon | Touch Screem: | Delta |
.
model |
W24S-45 Section Bending Machine |
|
Max. ant-bending section modulus of profile |
45cm3 |
|
yield limit of profile |
σs=250MPa |
|
Angel steel internal |
Max section |
75*75*10mm |
Minimum bending diameter |
1200mm |
|
Minimum section |
35*35*3mm |
|
Minimum bending diameter |
560mm |
|
Angel steel external |
Max section |
100*100*10mm |
Minimum bending diameter |
1100mm |
|
Minimum section |
35*35*3mm |
|
Minimum bending diameter |
800mm |
|
|
Channel steel external
|
Channel steel type |
16mm |
Minimum bending diameter |
1000mm |
|
|
Channel steel internal
|
Channel steel type |
16 |
Minimum bending diameter |
1000mm |
|
|
Flat steel vertical bending
|
Max section |
180*25mm |
Minimum bending diameter |
900mm |
|
Flat steel plane-bending |
Max section |
90*20mm |
Minimum bending diameter |
900mm |
|
|
Steel pipe bending
|
Max section |
Φ89*5mm |
Minimum bending diameter |
700mm |
|
H beam |
Max section |
165*304*6mm |
Min diameter |
50000mm |
|
Bending speed |
4 m/min |
|
Climb and Fall velocity of side roll |
180-200 mm/min |
|
Operating pressure of hydraulic system |
16MPa |
|
|
• 1 set of standard hardened and ground rolls (special steel) • All rolls Planetary/Gear – Hydro motor Driven • 3-axis hardened side supports with hydraulic forward-backward movement and mechanical up-down and right-left movement • Side supports are suitable for angle iron bending leg in -Leg Out • Portable control panel • Horizontal and Vertical operation • Body constructed of stress-relieved steel • Overload protection on hydraulic and electrical systems • Bottom rolls hydraulically adjustable with digital readout
|
