Specifications
hydraulic press brake price1,cnc control
2,protective backgauge
3,ball screw
hydraulic press brake machine
hydraulic press brake price
Feature and Advantages:
(1). This machine adopts hydraulic electric control, sliding block stroke can be adjusted, and have some fixed, semi-automatic, automatic movements such as norm, using dynamic specification can easily test and adjustment
(2). lift bending machine design, double oil cylinder work at the same time, balance, convenient operation, safety
(3). The dead point have confirmed when rolling function, ensure that the workpiece precision
(4). Under the condition of the relevant national standards, bending Angle precision of plus or minus 45 '. (refer to standard JB/T22572-1999)
(5). A slow decline control function, the operator can better control the workpiece
No | Name | Data | Unit | Remarks | |
1 | Nominal pressure | 1250 | KN |
| |
2 | Length of working table | 3200 | mm |
| |
3 | Plate strength | ≤450 | N/mm2 |
| |
4 | The distance of column | 2600 | mm |
| |
5 | Ram stroke | 150 | mm |
| |
6 | Max opening height | 415 | mm |
| |
7 | Depth of throat | 320 | mm |
| |
8 |
Ram speed | Free | 60 | mm |
|
Running | 7 | mm |
| ||
Return back | 60 | mm |
| ||
9 | Main | Type | Y160L-6 B5 |
| |
Power | 7.5 | KW |
| ||
Speed | 970 | rpm |
| ||
10 | Max pressure of system | 26 | Mpa |
| |
11 | Axial pump | Type | 25MCY14-1B |
| |
Speed | 25 | L/min |
| ||
Pressure | 31.5 | Mpa |
| ||
12 | Out size | Length | 3450 | mm |
|
Width | 1740 | mm |
| ||
Height | 2450 | mm |
| ||
13 | Weight | 7200 | kg |
| |
