WC67Y Series Sheet Metal Bending Machine

Name: WC67Y Series Sheet Metal Bending Machine
Brand: haiwei
SKU: 100729929
Availability: InStock

Nantong Teli Forming Machine Co., Ltd.

WC67Y Series Sheet Metal Bending Machine thumbnail-1

WC67Y Series Sheet Metal Bending Machine photo-1

US$ 85,000 - 120,000 MOQ: 1 Piece

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Jiangsu, China

Brand Name:

haiwei

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Jiangsu, China

Brand Name haiwei

Model Number WE67K-600/6000

Machine Type Press Brake

Raw Material Sheet / Plate Rolling

Material / Metal Processed Stainless Steel

Power Hydraulic

Automation Automatic

Extra Services End Forming

Certification ISO 9001:2000

After-sales Service Provided Engineers available to service machinery overseas

Specifications

sheet metal bending machine
1,standard top and down dies
2,Atos valves/siemens parts
3,DA41 cnc system
4,wo

sheet metal bending machine

WC67K-600/6000 hydraulic press brake

technical data:

No	Name		Data	Unit	Remarks
1	Nominal pressure		6000	KN
2	Length of working table		6000	mm
3	Plate strength		≤450	N/mm2
5	Ram stroke		300	mm
6	Max opening height		650	mm
7	Depth of throat		600	mm
8	Max bending thickness		16	mm
9	Distance of column		5420	mm

8	Ram speed	Free	80	mm
		Running	7	mm
		Return back	45	mm
9	Main	Type	Y280S-6 B5
		Power	45	KW
		Speed	980	rpm
10	Max pressure of system		26	Mpa
11	Gear pump	Type	NB5-G100F
		Speed	100	L/min
		Pressure	32	Mpa
12	Out size	Length	6300	mm
		Width	2800	mm
		Height	3600	mm
	Machine weight		60000	Kg

3, Performance:

3-1 All steel welded structure, vibrating treatment of aging for removal of internal stress with high strength and good rigidity.

3-2 Electro-hydraulic synchronization of mechanical limit stopper balance with high precision.

3-3 Integrated hydraulic transmission system, large range of speed regulation to transmission of the sliding block, stable and reliable performance.

3-4 Rear stopper and the sliding block have electrical adjustment for their stroke with manual fine tuning and digital indication.

3-5 Adjustment mechanism of sliding block independent from oil cylinder assembly to enhance sealing effect upper mold is fitted with titling warp offset mechanism.
