WC67Y Series Cnc Press Brakes Machine

FOB Price

US$ 85,000 - 120,000 / Piece

1 Piece(Min. Order)

Port shanghai
Payment TermsT/T L/C D/P D/A Money Gram Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Jiangsu, China
Brand Name	haiwei	Model Number	WE67K-600/6000
Machine Type	Press Brake	Raw Material	Sheet / Plate Rolling
Material / Metal Processed	Stainless Steel	Power	Hydraulic
Automation	Automatic	Extra Services	End Forming
Certification	ISO 9001:2000	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

WC67Y series cnc press brakes machine

WC67K-600/6000 hydraulic press brake

technical data:

No	Name		Data	Unit	Remarks
1	Nominal pressure		6000	KN
2	Length of working table		6000	mm
3	Plate strength		≤450	N/mm2
5	Ram stroke		300	mm
6	Max opening height		650	mm
7	Depth of throat		600	mm
8	Max bending thickness		16	mm
9	Distance of column		5420	mm

8	Ram speed	Free	80	mm
		Running	7	mm
		Return back	45	mm
9	Main	Type	Y280S-6 B5
		Power	45	KW
		Speed	980	rpm
10	Max pressure of system		26	Mpa
11	Gear pump	Type	NB5-G100F
		Speed	100	L/min
		Pressure	32	Mpa
12	Out size	Length	6300	mm
		Width	2800	mm
		Height	3600	mm
	Machine weight		60000	Kg

3, Performance:

3-1 All steel welded structure, vibrating treatment of aging for removal of internal stress with high strength and good rigidity.

3-2 Electro-hydraulic synchronization of mechanical limit stopper balance with high precision.

3-3 Integrated hydraulic transmission system, large range of speed regulation to transmission of the sliding block, stable and reliable performance.

3-4 Rear stopper and the sliding block have electrical adjustment for their stroke with manual fine tuning and digital indication.

3-5 Adjustment mechanism of sliding block independent from oil cylinder assembly to enhance sealing effect upper mold is fitted with titling warp offset mechanism.
