Std. 80+MIRO Reflector 100W LED High Bay Light

Name: Std. 80+MIRO Reflector 100W LED High Bay Light
Brand: ILEDING
Availability: InStock

FOB Price

US$ 20 - 60 / Piece

100 Pieces(Min. Order)

Port shanghai Port

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

LED Light Source	LED, LED	Warranty(Years)	5
Input Voltage(V)	120-277V, 120-277V	Lamp Power(W)	100, 100
Lamp Luminous Flux(lm)	10510	Lamp Luminous Efficiency(lm/w)	105
Color Temperature(CCT)	Other, 5000K	Working Temperature(℃)	-40, -20,
Working Lifetime(Hour)	35000, 35000	Lamp Body Material	Other
IP Rating	IP44	Certification	ETL, FCC, UL, FCC, UL, ETL
Place of Origin	Shanghai, China	Brand Name	ILEDING
Model Number	vapor

Product Description

Std. 80+MIRO reflector 100W LED high bay light

PRODUCT DESCRIPTION:

Ileding LED Linear High Bay Fixture with optional bi-level controls offers a classic fluorescent linear high bay housing with LM80- tested LED strips that resemble fluorescent tubes when lit. The same size and shape as a T8 fluorescent fixture, and improved with exceptional 100+ LPW output. The fixtures are constructed of sheet steel for heat sink and thermal control and a specular reflector for higher lumens.

Model Selection

Rated Power	Model No.	Lumen	CCT	Description
100W	RG-LHR100W-50K	11865	5000K	LED Linear High Bay, 120-277V, L46"W8"H2“, CRI80, Dimming (0-10V)
160W	RG-LHR160W-50K	17515		LED Linear High Bay, 120-277V, L46"W8"H2“, CRI80, Dimming (0-10V)
210W	RG-LHR210W-50K	23730		LED Linear High Bay, 120-277V, L46"W13"H2“, CRI80, Dimming (0-10V)
300W	RG-LHR300W-50K	33335		LED Linear High Bay, 120-277V, L46"W13"H2“, CRI80, Dimming (0-10V)

SPECIFICATIONS

Item	specification	Model
Item	specification	RG-LHR100W-XXK	RG-LHR160W-XXK	RG-LHR210W-XXK	RG-LHR300W-XXK
General Performance	Spacing Criteria	1.28(0°-180°)/ 1.26(90°-270°)	1.30(0°-180°)/ 1.30(90°-270°)	1.28(0°-180°)/ 1.26(90°-270°)	1.26(0°-180°)/ 1.26(90°-270°)
	Lumens Delivered(lm)	11865	17515	23730	33335
	Efficacy(lm/w)	110	110	110	110
	CRI	>83	>83	>83	>83
	Color Temp (CCT)	5000K
Electrical	Power Consumption	100W	160W	210W	300W
Electrical	Input Voltage	120-277ac
Physical	Dimensions	L46"W8"H2“	L46"W8"H2“	L46"W13"H2“	L46"W13"H2“
Physical	Weight	12.5lbs	15lbs	21lbs	21lbs
Certification	Certification	UL, FCC, LM79, DLC
	Material Usage	RoHS compliant, no mercury
	Environment	Indoor/Dry
	LED Class	LM-80,RU
	Warranty	5 Years
