Small Diesel Forklift CPC-20

Name: Small Diesel Forklift CPC-20
Brand: Laigong
SKU: 100711519
Availability: InStock

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

Laigong

Shandong Laigong Machine Manufacture Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name Laigong

Model Number CPC20

Type Powered Pallet Truck

Power Souce Diesel Engine

Rated Loading Capacity 2000kg

Max. Lifting Height 2150mm

Min. Lifting Height 110mm

Fork Length 1070mm

Fork Width 1100mm

Overall Dimensions 3870*1340*2150mm

Certification ISO

After-sales Service Provided Engineers available to service machinery overseas

Specifications

small diesel forklift CPC-20
1.brand: Laigong
2.engine: L28/ZN485Q
3 related loading 2000kg

small diesel forklift CPC-20

Model	CPC-20 (double mast)	CPC-20(single mast)
Engine model	L28/ZN485Q	L28/ZN485Q
Engine power(kw)	20/31	20/31
Machine weight(kg)	2950	2800
Overall length(mm)	3870	3870
Overall width(mm)	1340	1340
Overall height(mm)	2150	2150
Wheel base (mm)	1735	1735
Minimum ground clearance (mm)	110	110
Max.gradeability/full loading (%)	10	10
Speed/unloading(km/h)	15	15
Minimum turning radius(m)	2.4	2.4
Rated load (kg)	2000	2000
Fork length(mm)	1070	1070
Max adjust distance of fork(mm)	1100	1100
Load centre(mm)	500	500
Mast front rake	6°	6°
Mast caster	12°	12°
Max lifting height(mm)	2850	1650
Tire (front)	6.50-16	6.50-16
Tire (rear)	6.00-9	6.00-9
