Specifications
1.External Thread cam lever2.Cam lever with locking nut and washer
3.various of colors are available
petitive price
Cam lever, Adjustable cam lever, cam lever fastener,clamp lever
Cam Levers have one handle and are made of either Aluminum or Stainless Steel.
A variety of Mounting Types are also available including Adjustable Threaded Stud and Internal Threads.Handle length depend on the product you choose.
Cam lever fasteners allow for quick fastening and unfastening without the use of tools. They allow the user to tighten by threading like a traditional fastener however, for final tightening the cam lever is pushed downward. To unfasten, the cam lever is pulled up releasing the clamping force and allowing the fastener to be unthreaded. They are ideal for quick change operations where parts only have to be loosened and not completely unassembled.
Several different styles of cam levers are available to help suit an application’s need, including low profile, adjustable, and stainless steel variations.Hygoal offers the Cam Levers External Threads,Adjustable Cam Levers SS Internal Threads and the Adjustable Cam Levers.
Cam lever handles allow for quick fastening and unfastening without the use of tools.They thread in like a regular fastener but for the final clamp action the cam handle is simply pushed downward . They are constructed of cast aluminum and the washer is fiberglass reinforced plastic.
Base Diameter |
0.71 inch |
Component Material |
Carbon steel or Stainless Steel |
Handle Length (From Mount Center) |
2.77 inch |
Handle Material |
Aluminum |
Height (To Hinge Pin Center) |
0.57 inch |
Height (To Lever Top) |
0.87 inch |
Hinge Pin Diameter |
0.354 inch |
Measurement System |
Inch |
Mount Type |
Threaded stud |
Stud Length |
0.79 inch |
Thread Size |
10-32 |
Type |
SKU |
ROHS Compliance |
Yes |
Aluminum Cam Levers External Thread Inch and Metric :
| A | B | C | D | F | J | L | Item No. | |
| Inch | Carbon Steel | Stainless Steel | ||||||
| 10-32 | 0.354 | 0.790 | 0.710 | 0.570 | 0.870 | 2.770 | HG-C-026 | HG-C-058 |
| 10-32 | 0.354 | 1.180 | 0.710 | 0.570 | 0.870 | 2.770 | HG-C-028 | HG-C-060 |
| 10-32 | 0.354 | 1.570 | 0.710 | 0.570 | 0.870 | 2.770 | HG-C-030 | HG-C-062 |
| 10-32 | 0.354 | 1.970 | 0.710 | 0.570 | 0.870 | 2.770 | HG-C-032 | HG-C-064 |
| 1/4-20 | 0.354 | 0.790 | 0.710 | 0.570 | 0.870 | 2.770 | HG-C-034 | HG-C-066 |
| 1/4-20 | 0.354 | 1.180 | 0.710 | 0.570 | 0.870 | 2.770 | HG-C-036 | HG-C-068 |
| 1/4-20 | 0.354 | 1.570 | 0.710 | 0.570 | 0.870 | 2.770 | HG-C-038 | HG-C-070 |
| 1/4-20 | 0.354 | 1.970 | 0.710 | 0.570 | 0.870 | 2.770 | HG-C-040 | HG-C-072 |
| 5/16-18 | 0.433 | 0.980 | 1.060 | 0.710 | 1.120 | 3.780 | HG-C-042 | HG-C-074 |
| 5/16-18 | 0.433 | 1.180 | 1.060 | 0.710 | 1.120 | 3.780 | HG-C-044 | HG-C-076 |
| 5/16-18 | 0.433 | 1.570 | 1.060 | 0.710 | 1.120 | 3.780 | HG-C-046 | HG-C-078 |
| 5/16-18 | 0.433 | 1.970 | 1.060 | 0.710 | 1.120 | 3.780 | HG-C-048 | HG-C-080 |
| 3/8-16 | 0.433 | 0.980 | 1.060 | 0.710 | 1.120 | 3.780 | HG-C-050 | HG-C-082 |
| 3/8-16 | 0.433 | 1.180 | 1.060 | 0.710 | 1.120 | 3.780 | HG-C-052 | HG-C-084 |
| 3/8-16 | 0.433 | 1.570 | 1.060 | 0.710 | 1.120 | 3.780 | HG-C-054 | HG-C-086 |
| 3/8-16 | 0.433 | 1.970 | 1.060 | 0.710 | 1.120 | 3.780 | HG-C-056 | HG-C-088 |
| Metric | ||||||||
| M5 x 0.80 | 9.000 | 20.000 | 18.000 | 14.500 | 22.000 | 70.400 | HG-C-090 | HG-C-122 |
| M5 x 0.80 | 9.000 | 30.000 | 18.000 | 14.500 | 22.000 | 70.400 | HG-C-092 | HG-C-124 |
| M5 x 0.80 | 9.000 | 40.000 | 18.000 | 14.500 | 22.000 | 70.400 | HG-C-094 | HG-C-126 |
| M5 x 0.80 | 9.000 | 50.000 | 18.000 | 14.500 | 22.000 | 70.400 | HG-C-096 | HG-C-128 |
| M6 x 1.00 | 9.000 | 20.000 | 18.000 | 14.500 | 22.000 | 70.400 | HG-C-098 | HG-C-130 |
| M6 x 1.00 | 9.000 | 30.000 | 18.000 | 14.500 | 22.000 | 70.400 | HG-C-100 | HG-C-132 |
| M6 x 1.00 | 9.000 | 40.000 | 18.000 | 14.500 | 22.000 | 70.400 | HG-C-102 | HG-C-134 |
| M6 x 1.00 | 9.000 | 50.000 | 18.000 | 18.000 | 28.500 | 96.000 | HG-C-104 | HG-C-136 |
| M8 x 1.25 | 11.000 | 25.000 | 27.000 | 18.000 | 28.500 | 96.000 | HG-C-106 | HG-C-138 |
| M8 x 1.25 | 11.000 | 30.000 | 27.000 | 18.000 | 28.500 | 96.000 | HG-C-108 | HG-C-140 |
| M8 x 1.25 | 11.000 | 40.000 | 27.000 | 18.000 | 28.500 | 96.000 | HG-C-110 | HG-C-142 |
| M8 x 1.25 | 11.000 | 50.000 | 27.000 | 18.000 | 28.500 | 96.000 | HG-C-112 | HG-C-144 |
| M10 x 1.50 | 11.000 | 25.000 | 27.000 | 18.000 | 28.500 | 96.000 | HG-C-114 | HG-C-146 |
| M10 x 1.50 | 11.000 | 30.000 | 27.000 | 18.000 | 28.500 | 96.000 | HG-C-116 | HG-C-148 |
| M10 x 1.50 | 11.000 | 40.000 | 27.000 | 18.000 | 28.500 | 96.000 | HG-C-118 | HG-C-150 |
| M10 x 1.50 | 11.000 | 50.000 | 27.000 | 18.000 | 28.500 | 96.000 | HG-C-120 | HG-C-152 |
Custom Manufacturing:
Except these standard productsWe also supply customized sulotions or OEM according to your sample or drawings.
Hygoal Components manufactures a diverse range of custom plastic and metal products at extremely competitive costs - all from our facilities in Ningbo, China. Our teams have over a decade of manufacturing and supply chain management experience. From design concept, to sample creation, mass production and shipping. And we ensure your product arrives on spec, on time and on budget.
With the technical capability to rival all manufacturing facilities. We have the knowledge, experience and manufacturing capabilities to meet all of your requirement in customized solutions . For details of Hygoal's manufacturing procedure, please see our custom manufacturing overview page or contact with us.
Hygoal's Custom Manufacturing procedure:
|
Submit a technical drawing or post a sample » Use our enquiry form to send us a technical drawing of your product along with a description and the estimated quantity you require. If you do not have a technical drawing in most cases we can also reverse engineer from a sample. |
|
|
48hr quote from Hygoal sales team » We leverage the very latest technology and communications tools to unite our global teams. We understand the importance of fluid and responsive interactions between all aspects of the manufacturing process, from factory and quality control to shipping and distribution. Submit a technical drawing today and we'll quote in just 48 hours. |
|
|
High quality rapid tooling » Upon quote approval and receipt of your deposit payment, we begin fabrication of your tooling. When only a small number of parts are required, tooling can represent a large proportion of initial cost, but we are confident that our tooling costs will not be beaten. When a greater quantity of parts are produced the relative cost of tooling shrinks dramatically. |
|
|
Samples to your door in 35 - 40 days » The next step sees the first samples off the production line, and delivery to your door - but not before they've passed our meticulous quality control checks. We pride ourselves on getting the job done right the first time; we've worked successfully with countless companies whom require a manufacturing partner capable of keeping to close tolerances throughout production. If adjustments do need to be made, we'll perform them quickly and efficiently. |
|
|
Mass production in 4 weeks from sample approval » With injection moulding and die casting machines from 15 tonnes up to 3000 tonnes, you can be sure that we're ready for mass production. Our engineers are fastidious in their attention to detail; its imperative for both customer and manufacturer that the goods are on spec; you won't accept second rate products - we won't produce them. |
|
|
Packaged, labelled and shipped to your door in 10 weeks from sample approval » We understand our customers require much more than just first rate products, they need them securely packed and shipped to their destination on time. Our supply chain has been in successfull operation for over a decade, we'll even manage and monitor all customs, handling fees and insurance. |
|
