Specifications
small front end loader1. loaders with ISO certificate
2. rated loading capacity: 600kg
3. engine: Changchai L22
wheel horse front end loader
ISO certificate, 4 wheel drive
Mechanical operation
Standard bucket, 0.6 to payload
Changchai L22 single cylinder 21HP diesel engine
Common seat with safety belt, common steering wheel
Lockable fuel tank, electric fan
7.50-16 tyre
Performance |
Rated Loading: 600KG |
Bucket Capacity: 0.2CBM | |
Tread: 1,060MM | |
Wheel Base: 1,120MM | |
Min. Turning Radius: 3,800MM | |
Min. Ground Clearance: 290MM | |
Max Dump Height: 2,300MM | |
Dump Distance: 900MM | |
Lifting Time Of Bucket: 4.5S | |
Total Three Phases Time: 11S | |
Max. Breakout Force: 21KN | |
Overall Dimension: 4380x1350x2230MM | |
Operating Weight: 1745KG | |
Engine |
Model: Changchai L22 |
Type: Single Cylinder, Direct Injection, Horizontal, Four Stroke, Diesel | |
Cooling System: Hopper | |
Starting method: Electric Starting Motor | |
Engine Power: 15.5KW | |
Rated Speed: 2,200RPM | |
Specific Fuel Consumption: 244.8G/KW.H Max | |
Dimension: 858 X 450X 699MM | |
Net Weight: 180KG |
We have exported to Russia, Maylasia, India, Uzbekistan,Japan, Danmark, Africa and Latin America.
Loading quantity: 1unit/20GP,3units/40HQ
Some loading photos for your reference:
About our factory:
Our factory covers area of more than 100000m² with the building area of 35000m². At present it is the largest manufacturer of small construction machinery in China with annual output of loaders, forklifts and dump trucks
more than 40000units. Mechanical gearbox of the dumpers, loaders is the company's patented products.
Other products we supply:
1.wheel loaders zl04, zl06, zl08, zl10, zl12, zl15, zl16, zl18, zl20, zl25, zl30, zl50
2.dump truck fc10, fc15, fy15, fy20
3.mine specialty tricycle: ya14, ya17
Welcome your inquiry and visiting !
